T91 High Temperature Reheater Piping Leakage Analysis

Abstract:

Now T91steel is more and more used in power plant pipe components. The leakage of high temperature reheater pipe was analyzed after surveying the leaking site, checking material composition and observing the microstructure of related materials. We found that a large number of dust at the bottom of the pipe stopped the expansion of high temperature reheater tube rows, the connecting structure between pipes through fins was irrational, and welding fins process was substandard. Cracks were originated from fin-side weld, and extended to the pipe wall , which finally led to a leakage.
