Design and Realization of Hand-Held Smart Electrothermal Umbrella Applied New Materials

Abstract:

In this paper, a new type of hand-held smart eletrothermal umbrella has been designed and realized. Bionic lotus leaf polymer film, which is hydrophobic, is applied as umbrella fabric. Based on micro controller unit STC12C5A60S2, the system starts work with temperature sampling of outdoor environment by temperature sensor chip DS18B20, when the temperature is lower than 10°C, high current half bridge chip BTS7970 drives the carbon- nanofiber- electrothermal -heating- film to work. Also, the system is equipped with manual -heating module. A LED light of caution stands on the top of the umbrella that can flicker following a regular pattern controlled by MCU. A LED highlight is mounted at the bottom of the hand handle in order to illuminate the ground at night. Additionally, a USB interface, which can provide 5V output, is reserved to charge exterior electric device. The whole system is powered by eight 18650 lithium batteries, when fully charged, they can support the system working 8 hours constantly. With a synthesis of aesthetic, pragmatic function which can be expanded, and high performance, this new type of umbrella enjoys broad market and perspective.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 314-318
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.314
• Online since: December 2012
• Authors: Peng Gao*, Yan Ping, Gu Jing Han
• Keywords: Bionic Lotus Leaf Polymer Film, Carbon Nanofiber Electrothermal Heating Film, Self-Heating Hand Shank, Temperature Control

References

[1] Weilin Shi, Yefei Jin and Qian Xu. "Observing of Surface Microstructure Pearl in Bionic Materials by Scanning Electron Microscopy", Advanced Material Research Vol 531(2012).

DOI: 10.4028/www.scientific.net/amr.531.379

[2] Ma Zheng., Li Yaoming and Xu Lizhang. "Bionic desorption & damp-tiny material screening technology and their use in rape cleaning" 2011 International Conference on New Technology of Agricultural Engineering(ICAE) pages 189-193

DOI: 10.1109/icae.2011.5943781

[3] Microchip TechnologyInc. PIC16F87X Data Sheet 2001 [DB/OL] .http://www.microchip.com.(2002)

[4] LMAX LAKE. Lecture presented at conference[A]. Global Outlook for Carbon fiber 2002[c], Raleigh, NC.USA, 2002:21-23.

[5] Toshishige Yamada, Tsutomu Saito, Drazen Fabris, Cary Y.Yang "Electrothermal Analysis of Breakdown in Carbon Nanofiber Interconnects," IEEE ELECTRON DEVICE LETTERS,VOL 30,NO.5,MAY2009.

DOI: 10.1109/led.2009.2016361

[6] P.G. Clem, M. Rodriguez, J.A. Voigt and C.S. Ashley, U.S. Patent 6,231,666. (2001)

[7] M.Nihei, A Kawabata, D Kondo, M Horibe, S Sato, and Y.awano, "Electrical properties of carbon nanotube bundles for future via interconnects." Jpn, J.Appl.Phys, vol.44, no.4A, pp.1626-1628, 2005.

DOI: 10.1143/jjap.44.1626

[8] Zhongfu Zhao, Jihua Gou, "Processing and Structure of Carbon Nanofiber ". Journal of Nanomaterials - Special issue on nanocomposites for engineering applications January (2009)
