Road Load Spectrum Collection and Analysis of AMT Actuating Mechanism

Abstract:

Road load spectrum is not only the prerequisites of fatigue reliability analysis and test of AMT(Automated Manual Transmission) actuating mechanism, but also the input and boundary conditions of CAE(Computer Aided Engineering). Based on analysis of AMT motion and force, the measuring points of road load spectrum are determined, and the accelerometers and strain gauges are installed. Then the road load spectrum of AMT actuating mechanism is collected on Xiangfan Automobile Proving Ground according to related standards. At the same time the acquired road load spectrum is analyzed, such as pretreatment, repeatability checking and statistical analysis. The results indicate that the acquired road load spectrum is well reliable and repeatable, which provides effective basic data for design, analysis and verification of AMT actuating mechanism.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 895-898
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.895
• Online since: December 2012
• Authors: Xi Hong Zou, Kai Qiao, Xiao Hui Shi
• Keywords: Acquisition, AMT Actuating Mechanism, Analysis, Road Load Spectrum

References

[1] X. F. Yin, L. Li and Z. M. Liao: Journal of Mechanical Transmission, Vol. 34(2010)No. 8, p.87

[2] Y. T. Sheng, L. Zhang: Mechanical&Electrical Engineering Technology, Vol. 39(2010)No. ,p.113

[3] B. Felipe and L. Martins: SAE International, Vol 36(2009), p.243

[4] K. Si: Commercial vehicle engine, Vol. 10(2009), p.60

[5] M. Xin: Light Vehicles, Vol.2(2010), p.59

[6] V. Mauro, E. Bonisoli and E. Galvagno: SAE International, Vol. 1(2008), p.631

[7] V. Mauro, E. Bonisoli, E. Galvagno: SAE International, Vol. 24(2007), p.139

[8] GB/T 12534-90.Motorvehicles General Rules of Road Test Method[S],(1990)
