FEM Study on the Dynamic Effects of CMM Geometric Errors

Abstract:

Geometric errors are seldom considered the generations of CMM dynamic errors. This paper presents the dynamic effects of the geometric errors of CMM in fast probing, and investigates the properties with Finite Elements Method (FEM). The FEM model was composed of CMM moving bridge and its guide way. Presuming CMM guide way as an ideal rigid geometry, then angular errors were generated by the rotations of guide way around a corresponding coordinate axis, while translation errors came from the translations of guide way. Thus the 6 geometric errors on each guide way were completely decoupling and the corresponding dynamic effects were studied respectively. Analyses show that the angular errors around Y and Z-axes, Y(x) and Z(x), can induce remarkable dynamic effects at probe tip, especially in a CMM with low stiffness air bearing.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 972-975
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.972
• Online since: December 2012
• Authors: Yan Ling Chen, Yu Ning Peng, Zhong Hai Wei
• Keywords: Coordinate Measuring Machine, Dynamic Error, Fast Probing, Geometric Error

References

[1] Guoxiong Zhang, in: Coordinate Measuring Machine (in Chinese) [M]. Tianjin University Express, 2005.

[2] Pereira P. H., in: Characteristic and compensation of dynamic errors of a scanning coordinate measuring machine[J]. Precision Engineering, 2007(31):22-32.

DOI: 10.1016/j.precisioneng.2006.01.006
