Application Research of Fiber Bragg Grating for Sensing Finger Pressure Detection on High Voltage Isolate Switch

Abstract:

The sensing finger pressure does not meet the requirements can cause isolation switch overheating, even lead to accident in the operation of high voltage isolate switch. According to the structure of isolating switch, FBG pressure sensor and FBG displacement sensor are installed on isolate switch, which constitute the sensing finger pressure detection system. The sensing finger pressure detection experiments indicate that, when the moving contact’s closing position of isolate switch changes from 0.267mm to 29.040mm, the sensing finger pressure ranges from 30.378N to 32.970N.However, when spring pressure changes from 42.776N to163.827N, the sensing finger pressure ranges from 29.033N to 111.193N.The sensing finger pressure measuring system can realize real-time and online monitoring of the sensing finger pressure.

• Periodical: Advanced Materials Research (Volume 645)
• Pages: 342-345
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.645.342
• Online since: January 2013
• Authors: Tong Yao Yang, Chao Shen, Ya Ping Zhou, Ying Na Li, Tao Xie, Chuan Li
• Keywords: Displacement, Fiber Bragg Grating (FBG), Isolate Switch, Pressure, Sensing Finger Pressure, Sensor

References

[1] Bingli Qi, Zhong Meng, Yuchi Wang, Peng Kang, in: Research and development of 800kV High voltage AC isolate switch. High Voltage Apparatus, 2012, 48(4): 46-53.

[2] Chunxia Zhang, Weizhong Sun, et al, in: Analysis of cable sheath overvoltage due to not completely closing of GIS isolate switch. High Voltage Engineering, 2011, 37(10): 2498-2505.

[3] Zhenjiao Zhong, et al, in: Development of China's extra-high voltage disconnect switch. China Electrical Equipment Industry, 2006, (9): 42-48.

[4] Manfred Meinherz, Eckherd Wagner. US Patent 7378759B2, (2008).

[5] Yuxiu Shen, in: Measurement of sensing finger pressure of high voltage switch contact. High Voltage Apparatus: 1996, (3): 53-55.

[6] Ping Jiang, Jing Li, in: High voltage insulation switch stylus pressure test. Sichuan Electric Power Technology. 2009, 32(6): 26-28.

[7] Chuan Li, Yimo Zhang, Yonggui Zhao, in: Fiber Grating: Principle, Technology and Sensor Application Beijing: Science Press, (2005).

[8] Chuan Li, Chao Shen, Jialu Sun, in: A Method for Measuring Insulation Switch Stylus Pressure based on Fiber Bragg Grating Sensor. China, 201220073343. 7.
