Design and Performance Evaluation of a 10GHz 32nm-CNTFET IR-UWB Transmitter for Inter-Chip Wireless Communication

Abstract:

In this paper, we have presented the design and performance evaluation of a 10GHz 32nm-CNTFET IR-UWB transmitter for inter-chip wireless transmission. We have designed the transmitter using a VCO-based high speed clock generator and a positive and a negative monocycle Gaussian pulse generator. RF compatible Carbon Nano-Tube Field Effect Transistors (CNTFETs) have been used as the building blocks of the oscillator and the logic gates. The final design has resulted to a 7-channel-SWNT CNTFET-based transmitter for optimum 10GHz data rate with a promising 650mV pulse amplitude and only 1.069mW power consumption with a -32.27dB output. This transmitter can also operate satisfactorily upto 15GHz. The results show promising superiority over existing transmitters regarding high data rate, low power loss and high pulse amplitude.

• Periodical: Advanced Materials Research (Volume 646)
• Pages: 228-234
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.646.228
• Online since: January 2013
• Authors: Fahim Rahman, Prodyut Das, Md. Forhad Hossain, Sazzaduzzaman Khan, Rajib Chowdhury
• Keywords: Carbon Nanotube Field-Effect Transistor (CNTFET), Gaussian Pulse Generator, HSPICE, Inter-Chip Transmitter, Ultra-Wideband (UWB)

References

[1] International Technology Roadmap for Semiconductors, 2009 Edition. Available online: www. itrs. net.

[2] Ali Javey and Jing Kong (ed. ), Carbon Nanotube Electronics, Springer, (2009).

[3] M. F. Chang, V. P. Roychowdhury, L. Zhang, S. Hyunchol, and Y. X. Qian, RF/wireless interconnect for inter and intra-chip commun- ications, Proc. IEEE, vol. 89, no. 4, Apr. 2001, p.456–466.

DOI: 10.1109/5.920578

[4] B. A. Floyd, C. M. Hung and K.K. O, Intra-chip Wireless Interconnect for clock Distribution Implemented With Integrated Antenna, Receivers and Transmitters, IEEE Journal of Solid-State Circuits, Vol. 37, No. 5, 2002, pp.543-552.

DOI: 10.1109/4.997846

[5] Pran Kanai Saha, Nobuo Sasaki and Takamaro Kikkawa, A CMOS Monocycle Pulse Generation Circuit in a Ultra-Wideband Transmitter for Intra/Inter Chip Wireless Interconnection, Japanese Journal of Applied Physics, Vol. 44, No. 4B, 2005, pp.2104-2108.

DOI: 10.1143/jjap.44.2104

[6] M. A. Arafat, S.M.S. Rashid, A. Roy, and A.B.M. H. Rashid, A Simple High Data Rate UWB OOK Pulse Generator with Transmitted Reference for On-Chip Wireless Interconnects., in ICECE, December 2010, p.131—134.

DOI: 10.1109/icelce.2010.5700638

[7] Jan Plìva, Corrado Carta, Martin Claus, Michael Schroeter and Frank Ellinger, On the Design of Active Downconversion Mixers for Wireless Communications on a Carbon Nanotube FET Technology, Tran. of International Microwave & Optoelectronics Conference (IMOC), Oct. 2011, p.984.

DOI: 10.1109/imoc.2011.6169285

[8] I. Opperman, M. Hamalainen, and J. Iinatti, UWB theory and applications. JohnWiley and Sons, (2004).

[9] Xia Lingli, Huang Yumei and Hong Zhiliang, A fully integrated BPSK amplitude and spectrum tunable transmitter for IR-UWB system, Journal of Semiconductors, Vol. 30, No. 1, January (2009).

DOI: 10.1088/1674-4926/30/1/015006

[10] J. Deng and H. -S.P. Wong, A Compact SPICE Model for Carbon Nanotube Field Effect Transistors Including Nonidealities and Its Application – Part I: Model of the Intrinsic Channel Region, IEEE Transactions on Electron Devices, vol. 54, 2007, p.3186.

DOI: 10.1109/ted.2007.909030

[11] J. Deng and H. -S.P. Wong, A Compact SPICE Model for Carbon Nanotube Field Effect Transistors Including Nonidealities and Its Application – Part II: Full Device Model and Circuit Performance Benchmarking, IEEE Transactions on Electron Devices, Vol. 54, 2007, p.3195.

DOI: 10.1109/ted.2007.909043

[12] H, Kim, D. Park, and Y. Joo, All-digital low-power CMOS pulse generator for UWB system, IEE Electronics letter, vol. 40, no. 24, pp.1534-1535, November (2004).

DOI: 10.1049/el:20046923

[13] Y. Zheng, Y. Zhang, Y. Tong, A Novel Wireless Interconnect Technology Using Impulse Radio for Interchip Communications, IEEE transactions on microwave theory and techniques, vol. 54, no. 4, April (2006).

DOI: 10.1109/tmtt.2006.872070

[14] Y. Wang, K. Iniewski, V. Gaudet et al A CMOS IR-UWB Transceiver Design for Contact-Less Chip Testing Applications, IEEE transactions on circuits and systems—ii: express briefs, vol. 55, no. 4, April (2008).

DOI: 10.1109/tcsii.2008.919502

[15] Afroz, S; Amir M.F. ; Saha,A. ; Harun-Ur-Rashid A.B. M, A 10GBPS UWB transmitter for wireless inter-chip and intra-chip communication., In ICECE, December 2010. P. 104-107.

DOI: 10.1109/icelce.2010.5700637
