Simulation on the Transient Thermal Stress Field of the Wall-Shaped Part Deposited by Laser Direct Metal Powder Deposition

Abstract:

A thermo-kinetic model for the transient thermal stress field of the wall-shaped part produced using laser direct powder deposition process is developed. In case of numerical modeling, the capabilities of ANSYS parametric design language and the the ‘birth and death’ element technique were employed. The distribution of the thermal stress of the wall-shaped part at different time was calculated by the model. Results show that during process, the X-direction thermal stress within top layer of the wall-shape part and that within the interior deposited layers of the wall-shape part was tensile stress and compressive stress, respectively. The deformation of the wall-shaped part and base plate was also calculated.

• Periodical: Advanced Materials Research (Volume 647)
• Pages: 659-663
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.647.659
• Online since: January 2013
• Authors: Ming Zhe Xi
• Keywords: 316L Stainless Steel Powder, Finite Element Analysis (FEA), Laser Direct Powder Deposition, Transient Thermal Stress Field

References

[1] P.C. Collins, R. Banerjee, S. Banerjee, H.L. Fraser, Laser deposition of compositionally graded titanium-vanadium and titanium-molybdenum alloys, Materials Science and Engineering A352 (2003) 118-128.

DOI: 10.1016/s0921-5093(02)00909-7

[2] J.O. Milewski, P.G. Dickerson, R.B. Nemec, G.K. Lewis, J.C. Fonseca, Application of a manufacturing model for the optimization of additive processing of Inconel alloy 690, Journal of Materials Processing Technology 91 (1999) 18–28.

DOI: 10.1016/s0924-0136(98)00412-9

[3] R. Jendrzejewski,I. Kreja, G. ´ Sliwi´nski, Temperature distribution in laser-clad multi-layers, Materials Science and Engineering A 379 (2004) 313–320.

DOI: 10.1016/j.msea.2004.02.053

[4] Weixue Tian, Wilson K.S. Chiu, Temperature prediction for CO2 laser heating of moving glass rods, Optics & Laser Technology 36 (2004) 131 -137.

DOI: 10.1016/s0030-3992(03)00145-2

[5] M. Labudovic, D. Hu, R. Kovacevic, A three dimensional model for direct laser metal powder deposition and rapid prototyping, Journal of Materials Science 38 (2003) 35– 49.

[6] M.Z. Xi, Y.Z. Zhang, L.K. Shi, S.Y. Gao, R. Vilar, Analysis of the 3D transient temperature field during laser direct deposition of a 316L stainless steel thin wall, 4th International Conference on Laser Assisted Net Shape Engineering-LANE2004, Sept. 21-24, 2004, Erlangen, Germany, 611-620.

[7] L. Costa, R. Vilar, T. Reti, A.M. Deus, Rapid tooling by laser powder deposition: Process simulation using finite element analysis, Acta Materialia (2005), article in press.

DOI: 10.1016/j.actamat.2005.05.003

[8] A.H. Nickel, D.M. Barnett, F.B. Prinz, Thermal stresses and deposition patterns in layered manufacturing, Materials Science and Engineering A317 (2001) 59–64.

DOI: 10.1016/s0921-5093(01)01179-0

[9] Zhengqiao Wang, Youlin Wu, Stainless steel, China chemical industry press, (1991), 138-139.

[10] Zhengbao Su, Pufan Zhu, Huiguo Lin, Tieshan Yu, Alloy-steel manual, vol. 2, The first fascicule, revised edition, China metallurgical industry press, (1992), 49-52.
