The Development of the Closed-Loop Control System for the Mechanical Suspensions Test Rig

Abstract:

Frequency and amplitude of the existing mechanical suspension performance test rig can not change. And it has signal function. Frequency changing devices and amplitude adjustment mechanism were designed on it by study. Frequency and amplitude of the improved test rig can change within a certain range. It has two control algorithms: fixed-frequency vibration and sweep vibration. And the used closed-loop control in the system ensures the reliability of the system. The results show feasibility and correctness of this control system by a large number of experiments. It improves the function of the test rig and decreases the cost of study.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 1361-1364
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.1361
• Online since: January 2013
• Authors: Yan Liu
• Keywords: Amplitude Adjustment Mechanism, Closed-Loop Control, Frequency Changing Devices, Mechanical Suspensions Test Rig

References

[1] Tom Denton: Automobile Electrical and Electronic Systems, SAE. (1995).

[2] Thomas W. Birch: Automotive Suspension and steering System. (1998)

[3] Hrovat D.: Survey of advanced suspension developments and related optimal control application, Automation (1997).

[4] Dechang Xi, Xin Zhao: Shaking table and vibration test, Mechanical Industry Publications(1985). (In Chinese)

[5] Xinghua Pang: Mechanical Design, Electronics Industry Publications(2010). (In Chinese)

[6] Xiaofeng Bao: Car experiments and testing, Mechanical Industry Publications(1995). (In Chinese)

[7] Zhisheng Yu:Car theory, Mechanical Industry Publications(2008). (In Chinese)

[8] Junzheng He: Principles of Automatic Control, Chongqing University Publications(1994). (In Chinese)

[9] Ming Wang, In Chinese:Visual C++6.0 Programming, Electronics Industry Publications(2000). (In Chinese)
