The Design of Mechanical Arm of Hot Extruding and Upsetting Machine Based on SolidWorks

Abstract:

This paper established a model of mechanical arm of hot extruding and upsetting machine. According to design requirements of mechanical arm of hot upsetting extruding machine, established the 3D model of parts and the parts assembly by using 3D modeling software SolidWorks. This design realizes cyclical movement of mechanical arm that 120° level rotation and up-downswing 15° by incomplete gear mechanism and cam mechanism, and verified the feasibility of designing the project by SolidWorks.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 269-272
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.269
• Online since: January 2013
• Authors: Li Gang Wen, Hai Tao Wu, Hong Bin Liu
• Keywords: 3D Model, Mechanical Arm, SolidWorks
