Analysis about the Influence of Load on Loss of the Ceramic Spindle

Abstract:

The increase of loss causes the temperature rise in motor, reducing the using life of spindle, which can seriously affect the performance of motor. Thus, accurate calculating of loss is meaningful to optimal design of electric spindle. In this paper, the losses both with load and without load were analyzed by time-step finite element method. As the result of simulation analysis, the spindle losses with load are higher than those without load. Comparison analysis indicates that losses are various with different load. And the load impacts on core loss mostly in ceramic spindle. In addition, in asynchronous ceramic spindle with 4N•m rated load, the core loss, solid loss and stranded loss are least when the load change from 1.8 N•m to 3.8N•m. Accordingly, the best operation condition under the influence of load in electric spindle is gained.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 542-546
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.542
• Online since: January 2013
• Authors: Li Xiu Zhang, Meng Yuan Xu, Yu Hou Wu, Wan Lei Xia
• Keywords: Ceramic Spindle, Load, Loss, Time-Step FEA

References

[1] Yuqing Liu, Li Li: submitted to Journal of Advanced Technology of Electrical Engineering and Energy(2002), Vol. 21（2）：p.29-P31.

[2] Shuting Wan, Heming Li, Yonggang Li: submitted to Journal of Vibration and Shock(2005), Vol. 24（6）：p.21-P23.

[3] Wenzhu Li: Research on the Influence of Airgap Changer on the Performance of Linear Induction Motor, JiLin Unversity(2006).

[4] Shanlin Jiang: High-speed Permanent Magnet Synchronous Motor Loss Analysis and Temperature Field Calculation, Harbin Instituste of Technology(2010).

[5] Ningze Ling: Magnetic force and stator vibration analysis of large and medium-sized induction motor, Shenyang University of Technology(2006).

[6] Bo Zhao, Hongliang Zhang: Application of Ansoft 12 in Engineering electromagnetic field, chapter, 2, China WaterPower Press(2010).
