Forced Vibration of Rotor Suppressed by a Automatic Ball Balancer (Nonlinear Principal Resonances)

Abstract:

The automatic ball balancer is equipment used to balance the rotor system online and control its forced vibration. Although the rotor system is a nonlinear system actually, especially the occurrence of the nonlinear elastic restoring force in the support of rolling elements bearings, many researches still focus on the linear rotor systems at present. The Jeffcott rotor acted by unsymmetrical nonlinear restoring force is studied in this paper. Through the resolving theoretically and simulating numerically, the principal resonance respond of the rotor system controlled by the balancer with two balls and its stability are studied, while the vibration characteristics and movement laws of the rotor and balls in every rotary speed region are analyzed. The results showed that the balancer can suppress the principal vibration of the nonlinear rotor system in high speed region very well.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 551-557
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.551
• Online since: January 2013
• Authors: Xiao Long Zhang, Ya Bin Dong, Yu Min He, Mei Juan Tong
• Keywords: Balls, Nonlinear, Principal Resonances, Rotor System, Suppression of Vibration

References

[1] Thearle E L: A New Type of Dynamic Balancing Machine. Transactions of the ASME Vol. 54(1932) pp.131-141.

[2] Junkichi Inoue, Yasusuke Jinnouchi: The Dynamic Behavior of an Automatic Balancer. Transactions of the Japan Society of Mechanical Engineers. C Vol. 45(1979) pp.646-652.

DOI: 10.1299/kikaic.45.646

[3] L. Sperling, B. Ryzhik, Ch. Linz and H. Duckstein: Simulation of two-plane automatic balancing of a rigid rotor. Mathematics and Computers in Simulation Vol. 58(2002) p.351–365.

DOI: 10.1016/s0378-4754(01)00377-9

[4] D.J. Rodrigues , A.R. Champneys, M.I. Friswell and R.E. Wilson: Automatic two-plane balancing for rigid rotors. International Journal of Non-Linear Mechanics Vol. 43(2008) p.527 – 541.

DOI: 10.1016/j.ijnonlinmec.2008.01.002

[5] Zhang Xiaolong and Dong Yabin: Dynamic Mechanism of Unbalancing Response of Rotor Controlled by Balls Automatically. Journal of Mechanical Engineering Vol. 45(2009) pp.95-100.

DOI: 10.3901/jme.2009.07.095

[6] Yukio Ishida, Zhang XiaoLong, Jun Liu and Tsuyoshi Inoue: Suppression of Nonlinear Resonances by an Automatic Ball Balancer. The Japan Society of Mechanical Engineers, Dynamics & Design Conference (2008).

[7] Tsuyoshi Inoue, Yukio Ishida and Hideaki NIIMI: Vibration Analysis of a Self-Excited vibration in a Rotor System Caused by a Ball Balancer. ASME Journal of Vibration and Acoustics Vol. 134(2012).

DOI: 10.1115/1.4005141

[8] Jun Liu and Yukio Ishida: Vibration Suppression of Rotating Machinery Utilizing Automatic Ball Balancer and Discontinuous Springs Characteristics. ASME Journal of Vibration and Acoustics Vol. 131(2009).

DOI: 10.1115/1.3142872

[9] Toshio Yamamoto andYukio Ishida: Linear and Nonlinear Rotordynamics: a Modem Treatment with Applications (John Wiley & Sons Inc., U.S.A. 2001).
