Fluid-Structure Coupling Analysis of Traveling Wave Micro-Pump

Abstract:

The generation method of traveling wave and the driving force source in straight micro channel were investigated based on the vibration theory. The analysis shows that the driving force in traveling wave micro-pump is closely related to the fluctuations of the channel wall and there is traveling standing wave along the straight micro channel. Through fluid-structure coupling analysis, flow characteristics in straight micro channel are obtained as well as the outlet velocity. The average outlet velocity is about several hundreds of nanometers percent second if only the mechanical force is considered. The influence of the driving voltage on the velocity is also analyzed to provide guidance on the optimal design of the traveling wave micro-pump.

• Periodical: Advanced Materials Research (Volume 662)
• Pages: 572-575
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.662.572
• Online since: February 2013
• Authors: Chang Zhi Wei
• Keywords: Fluid-Structure Coupling Analysis, Micro-Pump, Traveling Wave

References

[1] HUIKKO K, KOSTIAINEN R, KOTIAHO T. Introduction to micro analytical system: bioanalytical and harmaceutical applications. European Journal of Pharmaceutical Sciences, 2003, 20(3): 149-171.

DOI: 10.1016/s0928-0987(03)00147-7

[2] YIN F, FUNG Y C. Comparison of theory and experiment in peristaltic transport. Journal of Fluids Mechanics, 1971, 47: 93–112.

[3] YOSEPH B C, ZEN S C. Piezoelectrically actuated miniature peristaltic pump. Proceedings of the SPIE Smart Structures Conference, 2000, 3992: 1-8.

[4] SUZUKI T, HATA H, SHINTAKU H, et, al. Visualization and optimization for fluid flow of traveling wave micropump. Proceedings of Micro Total Analysis System, 2005, 9: 1108-1110.
