Monitoring System of CAN Bus Based on OPC Technology

Abstract:

Through the comparison of many monitoring system’s schemes, the bus way of monitoring system was select which is based on CAN bus, using the PCI-5110 CAN interface card which is produced by ZHOU Li-gong company as the CAN node, selecting the CAN485MB intelligent protocol converters as their communication bridge between the CAN interface card and AI instrument. The system adopts the OPC technology to realize the communication between Kingview and CAN bus and builds a monitoring system based on CAN bus network to realize the function of the process control experiment platform of the real-time monitoring and graphical interface. Having friendly MMI, good flexibility, the whole system is worth to popularize and publicity.

• Periodical: Advanced Materials Research (Volume 662)
• Pages: 713-716
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.662.713
• Online since: February 2013
• Authors: Yu Qin Song, Chun Li Li
• Keywords: AI Instrument, CAN Bus, Kingview, OPC

References

[1] Na Wang, Ji-qiang Xia, Connecting tool for CAN bus and Configuration software [J]. Industrial control computer, 2006, 19 (1), pp.42-43. (In Chinese).

[2] Zhi-hua DENG, Xia-lin NI, Data Access for CAN with OPC [J]. Automation technology and application. 2005, 24 (9), pp.29-30. (In Chinese).

[3] Li-hong SHI, Data Exchange Between Kingview and CAN Bus Based on OPC [J]. Coal mine machinery, May 2005, pp.67-68. (In Chinese).

[4] Zheng LI, Ai-dong XU, Application of OPC Technology in Remote Monitoring and Maintenance System [J]. Instrument Technical and sensor, May 2006, pp.24-26. (In Chinese).
