Developing a DSP-Based Control System of Servo Punch Press Using Model-Based Method

Abstract:

Servo punch press uses a servo motor to drive. It can set different stroke length and velocity according to different production requirements, and can always ensure the formation precision of the bottom dead center. It has the advantages of high efficiency, high precision and low noise, and it presents the development trend of punch press. The key point of the servo punch press development is its control system. According to the functional requirements and technical performance of the servo punch press, the general approach of the servo punch press material forming control law is discussed in this paper. The development platform based on DSP control system has built up as well. By means of the Simulink and the Target for TI C2000 tools in Matlab, the dynamic model of punch press system and controlling model, including forming model, DSP-based controller model and plant model,etc., have been designed. Base on this, the forming characteristics of different materials, forming control algorithms have been studies through simulation and virtual experiments.The controller algorithm can be transferred automatically to the target controller. This approach can reduce developing time and costs of servo punch press control system and improve developing efficiency.

• Periodical: Advanced Materials Research (Volume 663)
• Pages: 465-469
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.663.465
• Online since: February 2013
• Authors: Jian Jun Yi, Fei Luo, Bai Yang Ji, Hui Jiang, Shao Li Chen
• Keywords: ARM, Digital Signal Processor (DSP), Forming Law, MATLAB/SIMULINK, Servo Punch Press

References

[1] Shi-Wenming. Komatsu presses mechanical characteristics. 1996(3).

[2] Wang-Guilian. Research of Punch Numerical Control System Based on Dual MCU. 2005. 3. 15.

[3] Yi-HongLong, Zu-DeZhou, QuanLiu, Ben-YuanChen, Heng-LinZhou. Embedded-based Modular NC Systems. 2008-4.

[4] Zuo-Peilun, LI-Chenghe. The Development of Servo Press. China Machine Press. 2006(7): 98-106.

[5] Jiang-Yan. A Design of Rapid Motion Control Prototype Based On xPC_Target[D]. East China University of Science Degree Thesis. 2008. 6.

[6] Liu-Heping, Deng-Li, Jiang-Yu. Principle, Structure and Basic Application of Digital Signal Processor-TMS320F28x [M]. China Machine Press. (2007).

[7] Guo-Wei, PAN Zhong-ming. Research on MATLAB Simulation Technology for DSP Control System [J]. MEASUREMENT & CONTROL TECHNOLOGY. 2006, 25(11): 55-58.

[8] Su-Baoying, Jin-Wei, Cao-Jianwei, Gu-Linyi. Research on Direct Analog-to-digital Conversion Technique for High Accuracy Weigh scale. China Machine Press. 2005, 22(5): 19-22.

[9] Guan-Yifeng. Research of DSP System Based on Embedded Target in Testing Machine's Servo Control System. Master. East China University of Technology School of Mechanical and Power Engineering. (2006).

[10] MATLAB Help Document. The Mathworks. (2007).
