Effect of Pin-Fin Material on Heat Transfer and Flow Resistance Characteristic of Rectangular Channel

Abstract:

Numerical simulation and experiments study were performed to obtain heat transfer and flow resistance characteristics in a channel with pin-fin arrays of trailing edge. Five models with different pin-fin materials were designed to simulate, which contained the rectangular duct model based on the flow and heat transfer of real blade, and four enlarged models with different pin-fin materials based on the similarity theory. One enlarged model was also experimented on, the simulation results of that model tend to agree with experimental data. The results of simulation show that the heat transfer coefficients of the rectangular channel wall increase with the thermal conductivity of pin-fin. And there is one thermal conductivity coefficient, which is determined by the Biot number of pin-fin, makes the average heat transfer of the enlarged model wall same as the real blade path model.

• Periodical: Advanced Materials Research (Volume 663)
• Pages: 490-496
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.663.490
• Online since: February 2013
• Authors: Hong Wu Deng, Yi Bang Wang, Wei Deng, Hui Min Sun
• Keywords: Coefficient of Thermal Conductivity, Heat Transfer, Pin-Fin

References

[1] Je - Chin Han , Sandip Duffa , Srinath V. Ekkad. Gas Turbine Heat Transfer And Cooling Technology. Taylor&Francis . (2000).

[2] Metzger D.E. , Shepard W.B. , Haley S.W. . Row resolved heat transfer variations in pin-fin arrays including effects of non-uniform arrays and flow convergence . International Gas Turbine Conference and Exhibit . (1986).

DOI: 10.1115/86-gt-132

[3] Metzger D.E. , Haley S.W. . Heat transfer experiments and flow visualization for arrays of short pin fins . American Society of Mechanical Engineers . (1982).

DOI: 10.1115/82-gt-138

[4] M. K. Chyu , Y. C. Hsing , V. Natarajan . Convective heat transfer of cubic fin arrays in a narrow channel . Journal of Turbomachinery . (1998).

DOI: 10.1115/1.2841414

[5] R.J. Goldstein , M.Y. Jabbari , S.B. Chen . Convective mass transfer and pressure loss characteristics of staggered short pin-fin arrays . Heat Transfer Laboratory . (1994).

DOI: 10.1016/0017-9310(94)90018-3

[6] I Jaswal , FE AmesHeat . Transfer and Pressure Drop Measurements in Constant and Converging Section Pin and Diamond Pedestal Arrays . Journal of Thermal Science and Engineering applications . (2009).

DOI: 10.1115/1.3159498

[7] Jenn-Jiang Hwang , Chau-Chin Lui . Detailed heat transfer characteristic comparison in straight and 90-deg turned trapezoidal ducts with pin-fin arrays . Department of Mechanical Engineering . (1999).

DOI: 10.1016/s0017-9310(99)00056-3

[8] Shih, TIP; Chi X; Bryden KM; Alsup C; Dennis RA. Effects of Biot Number on Temperature and Heat-Flux Distributions in a TBC-Coated Flat Plate Cooled by Rib-Enhanced Internal Cooling. Proceedings of the Asme Turbo Expo 2009, Vol 3, Pts a and B, (2009).

DOI: 10.1115/gt2009-59726

[9] The editorial board of China Aeronautical Materials Handbook. China Aeronautical Materials Handbook. Beijing: Standards Press of China. (2002).
