Research on the Shear Nails on the Arch Foot of an Oblique Cross Steel Box Arch Bridge

Abstract:

In order to find the distribution rules on the shear nails on the steel-concrete composite segment of arch foot of an oblique cross steel box arch bridge, it established a space finite element model through the engineering of Wenzhou Weiwulu oblique cross steel box arch bridge, analyzing the maximum shear stress of the shear nails under normal using stage. The result shows that the welding nails in different position have a great difference in their shear stress. The welding nails which welded in a place that has a greater stiffness bear a bigger shear stress. So their mechanical performance of steel-concrete segment is better. In addition, the maximum shear stress becomes bigger from the bottom up to the top of the steel box.

• Periodical: Advanced Materials Research (Volume 663)
• Pages: 49-54
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.663.49
• Online since: February 2013
• Authors: Xin Huang, Z.Z. Bai, De Wei Chen
• Keywords: Arch Foot, Finite Element Analysis (FEA), Shear Nails, Shear Stress, Steel Box Arch Bridge, Steel-Concrete
