Numerical Simulation Study of Impinging Jet Impact Fin Surface on Heat Transfer Characteristics

Abstract:

Three-dimensional numerical simulation was implemented to analyze the heat transfer characteristics for jet impingement impact fin surface. 60 calculation cases were simulated to investigate the effects of different fin surfaces on heat transfer characteristics, and 12 jet array impingement cases were calculated for comparison. The results shown that the fin shape, the height and the fin arrangement were the critical factors to affect the jet impingement and the best combination were existed in a certain range. The thermal resistance of cylinder fin arranged in order was34.7 percent higher than that of cylinder fin arranged staggered. The thermal resistance of square fin arranged in order was38.9 percent higher than that of square fin arranged staggered .The heat transfer coefficients of impinging jet impact fin surface were better than that of jet array impingement. The fitting correlations on heat transfer of impinging jet impact fin surface were given.

• Periodical: Advanced Materials Research (Volume 663)
• Pages: 586-591
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.663.586
• Online since: February 2013
• Authors: Li Ming Zhou, Lei Zhu, Jing Quan Zhao, Meng Zheng
• Keywords: Heat Transfer Coefficient (HTC), Jet Impingement, Numerical Calculation

References

[1] Li Changgeng. Research on Cooling Method of Electronics Based on Jet Impingement [D]. Central South University. (2009).

[2] MenterF.R. Two-Equation Eddy-Viscosity Turbulence Models for Engineering Applications[J]. AIAA Journal, 1994, 32(8): 1598-1605.

DOI: 10.2514/3.12149

[3] Intel Pentium 4 Process on 90 nm Process Datasheet[J]. Intel technical documents, 2005; 63-69.

[4] XieHao. Numerical Simulation of jet array impingement cooling on flow and heat transfer characteristics[J]. 2005, (23).

[5] Intel Pentium 4 Processor on 90nm Process Datasheet[J]. Intel technical documents, 2005: 63-69.

[6] Tao Wenquan. Heat transfer theory[M] Xi'an Jiao tong University, 1995, 243-249.
