Design of MK1432/H CNC Precision Cylindrical Grinding Machine

Abstract:

MK1432/H CNC precision cylindrical grinding machine is suitable for precision grinding IT6 to IT5 cylindrical or conical revolving workpiece, the table of the rail bed for the paste with plastic rail, the first holder of the rotating dial tone from the motor frequency speed, with Germany's Siemens 810D CNC two-axis system, built-in PLC, liquid crystal display. Servo motor is 1FK6 series; configure automatic measuring instrument line detection, automatic grinding work to achieve closed-loop cycle, ensuring high machining dimensional accuracy. Machine bed using a large round hole, fin-shaped reinforcement plates, Bench points up and down the table, you can grinding conical, bed and table in the guide rail for the laminating, the friction coefficient is small, table driven by a servo motor directly to the Deputy move the ball bar, smooth and reliable movement. Mainly used in automobile, motorcycle parts factory and other machinery manufacturing industry, for the grinding disc type, short axis, and taper shank type etc. parts.

• Periodical: Advanced Materials Research (Volume 670)
• Pages: 22-25
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.670.22
• Online since: March 2013
• Authors: X.J. Wang, X.G. Fu
• Keywords: Control System, Mechanical Design, MK1320

References

[1] S.L. Tu, Microcontroller MCS - 96 / 98 utility routines, Fudan University Press, Shanghai, (1991).

[2] Q.S. Yang, Modern Microcomputer Principle and Interface Technology, Electronic Industry Press, Beijing , (2002).

[3] D.H. Zhu, Microcontroller Theory and Interface Technology Experiment, Tsinghua University Press, Beijing, (2002).

[4] Z.Y. Yu, NC machine tool maintenance, Machinery Industry Press, Beijing, (2001).

[5] Y.J. Yang, Digital control technology and CNC machine tools, Machinery Industry Press, Beijing, (1999).

[6] D.N. Chen, Mechanical equipment control technology, Machinery Industry Press, Beijing, 1999).
