Simulation and Optimization of Energy Saving Distillation Process for High-Purity Trichlorosilane with Material Properties

Abstract:

In order to reduce the production cost of polysilicon, the raw material of the photovoltaic industry, applying heat integrated distillation technology of two towers in trichlorosilane distillation process consisting of removal of light components after removing heavy components. By assistant of a chemical process software, the new energy-saving process is simulated, the main parameters of two towers are optimized and the best implementation solution are provided. The optimum parameters for the first tower are the operation pressure of 500 kPa, the number of theoretical plates of 32, the position of feed plate of 24, reflux ratio of 4.2 and the distillate to feed ratio of 0.8516. For the second tower, the operation pressure, the number of theoretical plates, the position of feed plate, the reflux ratio and the bottoms to feed ratio are 250 kPa, 74, 15, 111 and 0.9652 respectively.The results showed that the new process can save energy consumption up to 50%, the coefficient of recovery for trichlorosilane is up to 98.7% while the high purity of trichlorosilane can ensure the resulted polysilicon excellent photovoltaic properties.
