Voltage Flicker Detection Method Based on Teager Operator

Abstract:

Fast and accurately detection of voltage fluctuation components is very important to voltage flicker measurement. A novel voltage flicker demodulation algorithm based on Teager operator is proposed in this paper. The principle of the Teager operator demodulation approach is introduced, and the mathematical derivation of the proposed algorithm is described. The proposed algorithm is fast and requires only a few samples to calculates, therefore, it has excellent time resolution. The simulation results prove that the new algorithm can track the flicker signal of unifrequency or multifrequency amplitude modulation wave successfully. The comparison result of proposed method, the square demodulation method and the Hilbert transform demodulation method shows that the proposed method has obvious advantages of calculation speed and detection accuracy.

• Periodical: Advanced Materials Research (Volume 677)
• Pages: 394-399
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.677.394
• Online since: March 2013
• Authors: Shuai Yuan, Jian Gang Bi
• Keywords: Demodulation Method, Envelope Tracking, Teager Operator, Voltage Flicker

References

[1] LIN Hai-xue. Introduction of the new national standard of 《power quality voltage fluctuation and flicker》 [J]. Distribution & Utilization, 2001, 18(6): 4~10.

[2] MA Yu-long, LIU Lian-guang, ZHANG Jian-hua, etc. RESEARCH OF DIGITAL FLICKERMETER BASED ON IEC STANDARD[J]. Proceedings of the CSEE, 2001, 21(11): 92~95.

[3] M T Chen. Digital algorithm for measurement of voltage flicker[J]. IEE Proceedings-Generation, Transmission and Distribution, 1997, 144(2): 175~179.

DOI: 10.1049/ip-gtd:19970683

[4] TONG Xiang-qian, YU Jian-min. Study on Detecting Method of Voltage Fluctuation in Supply Voltage[J]. Chinese Journal of Scientific Instrument, 1998, 19(3): 234~238.

[5] Halpin S M, Bergeron R, Blooming T M, et al. Voltage and lamp flicker issues: should the IEEE adopt the IEC approach[J]. IEEE Transactions on Power Delivery, 2003, 18(3): 1088~1097.

DOI: 10.1109/tpwrd.2003.814261

[6] WANG Zhi-qun, ZHU Shou-zhen, ZHOU, Shuang-xi. PARAMETER ESTIMATION OF VOLTAGE FLICKER THROUGH HILBERT TRANSFORM [J]. Automation of Electric Power Systems, 2004, 28(5): 34~38.

[7] Feilat E A. Detection of voltage envelope using Prony analysis-Hilbert transform method[J]. IEEE Transactions on Power Delivery, 2006, 21(4): 2091~2093.

DOI: 10.1109/tpwrd.2006.881983

[8] Shyh-jier Huang, Chen-wen Lu. Enhancement of digital equivalent voltage flicker measurement via continuous wavelet transforms[J]. IEEE Transactions on Power Delivery, 2004, 19(2): 663~670.

DOI: 10.1109/tpwrd.2003.820174

[9] P Maragos, J F Kaiser, T F Quatieri. Energy separation in signal modulations with applications to speech analysis[J]. IEEE Transactions on Signal Processing, 1993, vol.41: 3023~3051.

DOI: 10.1109/78.277799

[10] Alexandros Potamianos, et al. A comparison of the energy operator and the Hilbert transform approach to signal and speech demodulation[J]. Signal Processing, 1994, 37(1): 95~120.

DOI: 10.1016/0165-1684(94)90169-4

[11] Petros Maragos, et al. Energy separation in signal modulations with application to speech analysis[J]. IEEE Transactions on Signal Processing, 1993, 41(10): 3024~3051.

DOI: 10.1109/78.277799
