In-Process Visualisation for Deformation Monitoring and Analysis of Sheet Metal Forming Processes

Abstract:

In this paper, a visualisation system will be discussed that can be used to capture the deformation profile of the sheet blank during sheet metal forming processes, such as deep drawing and shape forming. The visualisation system utilizes a 2D laser displacement sensor for deformation profile acquisition. The sensor is embedded in the die and the laser propagates through the die to detect the profile change of the specimen concealed in the die during operation. The captured profile data will be collected, manipulated and transferred to a monitor for display via a controller. This visualisation of the deformation profile will provide engineers and researchers with an intuitive means of analysing and diagnosing the deformation process during sheet metal forming.
