Development of Metal Sheets Hydraulic Deep Drawing Tooling

Abstract:

A simple and practical hydraulic deep drawing test tooling is developed to investigate metal sheets formability. It is composed of two parts including the forming die and hydraulic control system. Experiments with varied material and dimensional sheets of hydraulic deep drawing and mechanical deep drawing can be fulfilled by the tooling on a Single-Action Press without complicate external hydraulic system, blank holder system and oriented system for punch, respectively. The tooling is testified to be simply, facile and reliable, which can perfectly perform the sheets forming in hydraulic deep drawing, and the formability of sheets was improved effectively with hydraulic deep drawing.

• Periodical: Advanced Materials Research (Volumes 706-708)
• Pages: 1286-1289
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.706-708.1286
• Online since: June 2013
• Authors: Xian Chang Mao, Si Li
• Keywords: Hydraulic Deep Drawing, Sheets, Tooling
