Dynamic Analysis of Gear Mesh for Gear Pump Based on ANSYS Workbench

Abstract:

Based on the FEA software ANSYS Workbench, the soft body dynamics performance of the gear pump gear mesh of a hydraulic pump company was analyzed. In the practical engineering applications, gear pump gear teeth are effected by alternating pressure in the two working cavity. It can cause pitting corrosion damage for gear tooth, and even cause tooth crack and fracture. At first, a three dimension finite element models of the gear pump gear teeth was established. In the start-up process, the gear pump tooth mesh deputy of tooth contact stress strain and dynamic characteristics of gear teeth was analyzed. Obtain the velocity curves, acceleration curve and tooth contact stress and strain dynamic curves of the tooth of gear pump. Providing a new analysis method for gear pump of gear Structure design and having a practical application value.

• Periodical: Advanced Materials Research (Volumes 706-708)
• Pages: 1290-1293
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.706-708.1290
• Online since: June 2013
• Authors: Lei Zhao, Qing Qing Lv, Li Quan Yang
• Keywords: Dynamic, Finite Element Analysis (FEA), Gear Mesh, Gear Pump

References

[1] Z.R. Liu: Master degree theses. Guizhou University, Guiyang, 2011.

[2] W.D. Luo, W.Lv, R.L. Shu:Journal of Coal Mine Machinery, 2009, 21 (4).p.89.

[3] L.Lei, B.L.Wu, X.B. Xie: Mechanical Drive, 2006, 21, p.53.
