Experimental Study of Modal Disturbance and Rotating Stall Distribution

Abstract:

To execute stall active control technology effectively and make clear of stall inception induced by modal disturbance, this paper carries out the correlative research on modal disturbance and rotating stall on the two-stage low-speed axial compressor. The results indicate that the stall inception of the compressor is modal style and the modal oscillation propagates at 38% rotor speed while the stall cell propagation speed is 42% rotor speed. The phase angles of modal oscillation and rotating stall along the axial direction are different, but their trajectories are both similar to the blade passage shape. The stall mechanisms of modal-type and spike-type inceptions are different. It doesnt appear that leading-edge tip clearance flow spillage blow the blade tip while the modal-type stall formation.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 1804-1810
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.1804
• Online since: July 2013
• Authors: An Qing Lai, Jun Hu, Liang Li, Ju Luo
• Keywords: Compressor, Modal Disturbance, Phase Angle, Rotating Stall

References

[1] N.M. McDougall: Stall Inception in Axial Compressor, Ph.D., Cambridge University, 1988.

[2] V.H. Garnier, A. H. Epstein and E. M. Greitzer, Rotating Waves As a Stall Indication in Axial Compressors. ASME Journal of Turbomachinery, 115(3):290~302, 1991.

DOI: 10.1115/1.2929105

[3] I.J. Day, Stall Inception in Axial Flow Compressors, ASME Journal of Turbomachinery, 115(1):1~9, 1993.

DOI: 10.1115/1.2929209

[4] Y. Gong, C.S. Tan, K.A. Gordon and E.M. Greitzer, A Computational Model for Short Wavelength Stall Inception and Development in Multi-Stage Compressors, ASME Journal of Turbomachinery, 121(4):726-734, 1999.

DOI: 10.1115/1.2836726

[5] C. Hah, J. Bergner and H.P. Schiffer, Short Length-Scale Rotating Stall Inception in a Transonic Axial Compressor- Criteria and Mechanisms, ASME Paper GT2006-90045.

DOI: 10.1115/gt2006-90045

[6] S. Weichert, I.J. Day, Detailed Measurements of Spike Formation in An Axial Compressor, ASME Paper GT2012-68627.

[7] H.D. Vo, C.S. Tan and E.M. Greitzer, Criteria for Spike Initiated Rotating Stall, ASME Paper GT2005-68374.

[8] C.Q. Nie, G. Xu, et al, Micro Air Injection and Its Unsteady Response in A Low-Speed Axial Compressor, Transactions of the ASME, 124(4):572-579, 2002.

DOI: 10.1115/1.1508383

[9] H. Khaleghi, J.A. Teixeira, A.M. Tousi and M. Boroomand, Parametric Study of Injection Angle Effects on Stability of Transonic Axial Compressors, AIAA J. Propulsion and Power, 24(5):1100-1107, 2008.

DOI: 10.2514/1.34817

[10] R.G. Stockwell, L. Mansinha and R.P. Lowe, Localization of the Complex Spectrum: The S Transform, IEEE Transactions on Signal Processing, 44(4):998~1001, 1996.

DOI: 10.1109/78.492555

[11] J.S. Bendat, A.G. Piersol, Engineering Applications of Correlation and Spectral Analysis, Wiley, New York, 1980.

[12] M. Inoue, M. Kuroumaru, Structure of Tip Clearance Flow in an Isolated Axial Compressor Rotor, ASME Journal of Turbomachinery, 111(3):250~256, 1989.

DOI: 10.1115/1.3262263
