Wide Frequency Band DC Corona Current Measurement and Analysis of Bundle Conductor Based on UHV Corona Cage

Abstract:

A wide frequency band DC corona current measurement system is introduced in this paper. GPS technology is applied to make sure that the voltage and current signal are collected synchronously. The wide band corona current signal is transmitted to the lower computer by the wireless network of 300M/s. The wide frequency band DC corona current waveform was gained in the Ultra High Voltage (UHV) Test Base in Wuhan, which can reflect the high frequency pulses of the corona current, and corona currents of 6 bundle conductor LGJ630-45 in dry and rain (rain rate 20mm/h) conditions are gained. The corona current in the rain condition is much larger than that in the dry condition.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 600-604
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.600
• Online since: July 2013
• Authors: Fang Cheng Lü, Lei Zhu, Yun Peng Liu, Qing Zhong Geng, Jun Zhu, Hang Juan Dai, Xiong Jie Xie
• Keywords: Corona Cage, GPS Synchronization, UHV, Wide Frequency Band Current, Wireless Network

References

[1] Z.Y. Liu, Ultra-high Voltage Grid, first ed., China Economic Press, Beijing, (2005)

[2] J.G. Anderson. Transmission Line Reference Book of 345 kV and Above, WHVRI translate, Power Industry Press, Beijing, 1981.

[3] J.J. Clade, C. H. Gary, Predetermination of corona losses under rain: experimental interpreting and checking of a method to calculate corona losses, J. Sci. IEEE Trans on PAS. 89(1970):853-860.

DOI: 10.1109/tpas.1970.292648

[4] T.N. Giao, M.P. Sarma. A method of predicting the corona performance of conductor bundles based on cage test results J. Sci. IEEE Trans on Power Apparatus and Systems. 98(1977): 312-325.

DOI: 10.1109/t-pas.1977.32339

[5] W.J. Gerhard, E.Z. Luciano. Radio noise, audible noise, and corona loss of EHV and UHV transmission lines under rain: predetermination based on cage tests, J. Sci. IEEE Trans on PAS. 89(1970):1168-1178.

DOI: 10.1109/tpas.1970.292728

[6] P.S. Maruvada. Corona performance of high-voltage transmission lines, first ed., Research Studies Press Ltd, London, 2000.

[7] S.S Li, X.Y. Chen. Corona Measurement Technology and Result on Test Lines. J. Ei. High Voltage Engineering. 32(2006):33-39.

[8] S.Y. Li. Application of optic technology in measurement of corona loss of HV transmission line J. Ei. Power System Technology.11 (1987):1-5.

[9] F.C. LÜ, S.H. You, Y.P. Liu, et al. Analysis on corona loss measurement of Ultra High AC Single Circuit Test line in Rain and Snow Weather Conditions. J. Ei. High Voltage Engineering. 37(2011): 2089-2095.

[10] Y.P. Liu, S.H. You, Q.F. Wan. Research on Corona Loss of UHV AC Double circuits Test Line on the Same Tower under Rain. J. Ei. High Voltage Engineering, 2011, 37(9):2149-2154.

[11] F.C. LÜ, S.H. You, Y.P. Liu, Q.F. Wan, et al. AC Conductors' Corona-loss Calculation and analysis, J. Sci. IEEE Trans on power delivery, 27(2012): 877-885.

DOI: 10.1109/tpwrd.2012.2183681
