Signal Acquisition Analysis in Hi-Speed and Hi-Precision MFL Testing for Steel Pipe

Abstract:

Dealing with the relationship properly between the sensor scanning and signal acquisition is the base of hi-speed and hi-precision MFL (magnetic flux leakage) testing for steel pipe. Firstly, the MFL wave form characteristic was established using magnetic dipole theory. Further, on that basis, the relationship between signal frequency and sensor scanning was analyzed. Finally, sample frequency was designed according to the requirement of the automatic steel pipe MFL testing. Additionally, the MFL signal acquisition experiment was conducted to verify the influence of the signal sampling frequency. The signal acquisition analysis was of great significant to perform the MFL testing for steel pipe in hi-speed and hi-precision.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 875-880
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.875
• Online since: July 2013
• Authors: Jian Bo Wu, Jun Tu, Yun Yang, Yi Hua Kang
• Keywords: Magnetic Flux Leakage (MFL), Sample Frequency, Signal Frequency, Steel Pipe

References

[1] API, "Petroleum and Natural Gas Industries-Steel Pipe for Pipeline Transportation Systems, Specification for Line Pipe," ANSI/API Specification 5L, No. 44, 2008.

DOI: 10.3403/30235500u

[2] Haitao Cheng. Defects and Prevention of Seamless Steel Pipe. Sichuan Science and Technology press,2007.

[3] Peiqing Chen. Signal Digital Processing Course. Tsinghua University Press, 2011:34-41.

[4] Jilin REN, Junming LIN. Electromagnetic Nondestructive Testing. Science Press, 2008:222-227.Yihua Kang

[5] Jianbo WU, Yanhua Sun, The use of Magnetic Flux Leakage Testing Method and Apparatus for Steel Pipe. Materials Evaluation, 70(7): 821-826, 2012.

[6] Dale Reeves, "Electromagnetic flaw detection apparatus for inspection of a tubular," US Patent 11387119, Mar, 2006.

[7] John P. Rogers, "Magnetic flux leakage system and method," US Patent 11591712, Nov, 2006.

[8] Randel Brandstrom, "Apparatus and method for detection of defects using flux leakage techniques," US Patent 11411235, Apr, 2006.

[9] Jim W. K. Smith, Burn Ross Hay, "Magnetic flux leakage inspection tool for pipelines," US Patent 6023986, Feb, 2000.

[10] Timothy K. Werni, "Multi-directional magnetic flux pipe inspection apparatus and method," US Patent 5454276, Jul, 1993.

[11] Foerster, Magnetic flux leakage testing with circoflux. Order No. 180846 (edition). Nov. 2007.

[12] Nestleroth, J. B., "Circumferential MFL in-line inspection for cracks in pipelines. FINAL Report." Grant agreement No. DE-FC26-01NT41159. June, 2003.

DOI: 10.2172/823144
