Analysis of Direct Cooling High Temperature SMES Device Leakage Magnetic Field Based on Finite Element Method

Abstract:

High temperature superconducting magnetic energy storage system (SMES) is a strong electromagnetic source with serious leakage magnetic field. Leakage magnetic field can cause certain effect to environment, which should be taken into consideration in the design process of high temperature SMES. Direct cooling high temperature SMES device was seen as research object. Two dimensional model of high temperature SMES device was built by using ANSYS, and the leakage magnetic field of SMES devices, whose cryostat are of different magnetic permeability, were compared. The security scope of SMES device was determined under operating condition. Research results can provide important guidelines for the design of the SMES device.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1193-1196
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1193
• Online since: August 2013
• Authors: Xiang Li, Gang Wu, Gang Zhou, Ke Bi, Zhi Yin Tang, Qing Zhi Zhang, Ji Ma
• Keywords: Finite Element Analysis (FEA), High Temperature SMES, Leakage Magnetic Field

References

[1] Honglin Xu, Huilin Wang and Ling Shi: Cryogenics, 2003, 5: 21~25(In Chinese).

[2] Taozhen Dai, Zeyang Fan and Jingdong Li: Engineering Science, 2002, 4(6): 16~19(In Chinese).

[3] Bin Shi, Yunjia Yu: Advanced Technology of Electrical Engineering and Energy, 1999, 18(4): 33~36(In Chinese).

[4] Wei Liang. The design and optimization of SMES coils [D] . Huazhong University of Science and Technology Master's Thesis, 2006: 40~41(In Chinese).

[5] Ming Song, Xiucheng Liu and Zanji Wang: Advanced Technology of Electrical Engineering and Energy, 2005, 24(4): 34~38(In Chinese).
