Influence of a Deep NBL Structure on ESD/Latch-Up Immunities in the Power Device nLDMOS

Abstract:

In this paper, we propose a novel high-voltage (HV) nLDMOS transistor with a small R_on resistance, low trigger voltage (V_t1) and high holding voltage (V_h) characteristics. Here, we introduce a deep N⁺-buried-layer (NBL) into this HV nLDMOS to evaluate the ESD/latch-up (LU) parameters variation. These electric snapback parameters affect the reliability of proposed device and its performance. Eventually, we expect this proposed HV stucture processed better characteristic behaviors, which can be applied to the power electronics and ESD protection application of HV ICs.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1207-1211
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1207
• Online since: August 2013
• Authors: Shen Li Chen, Tzung Shian Wu
• Keywords: Breakdown Voltage (V_bk), Electrostatic Discharge (ESD), Holding Voltage (V_h), Latch-Up (LU), N⁺ Burried Layer (NBL), N⁺-Type Buried Layer (NBL), nLDMOS, R_on Resistance, Trigger Voltage (V_t1)
