Implementation of a High Reliability IGBT Power Device

Abstract:

The insulating-gate bipolar transistor, IGBT, is a power component which is developed in the medium power and medium frequency. It inherently integrates the structures of a power bipolar transistor and a power MOSFET, and then it has better performance in many applications. Advantages of this device are the high current density, the outstanding breakdown voltage, as well as the excellent operating frequency and so on. And, it might make up the shortcoming of MOSFETs or BJTs utilized separately. In this paper, a smart IGBT device is developed by using the semiconductor process and device simulation tools. Therefore, a relationship between the depth of drift region, doping concentration, and breakdown voltage in an IGBT will be investigated in this work. Eventually, this device will be with the 200V breakdown voltage and 20A on-state driving current capability. Meanwhile, the ESD and latch-up (LU) protection structures will be accomplished in this study.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1202-1206
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1202
• Online since: August 2013
• Authors: Shen Li Chen*, Yi Tsai Hsueh
• Keywords: Breakdown Voltage (V_bd), Electrostatic Discharge (ESD), Insulated Gate Bipolar Transistor (IGBT), Latch-Up (LU)

References

[1] B.J. Baliga, M.S. Adler, R.P. Love, P.V. Gray, N.D. Zommer: IEEE Transactions on Electron Devices, Vol. 31, Issue 6 (1984), p.821.

DOI: 10.1109/t-ed.1984.21614

[2] Jae In Lee, Jongchan Choi, Young-seok Bae, Man Young Sung: 1st Asia Symposium on Quality Electronic Design (2009), p.370.

DOI: 10.1109/asqed.2009.5206237

[3] P. Bill, A. Welleman, E. Ramezani, S. Gekenidis, R. Leutwyler: IEEE Pulsed Power Conference, (2011), p.1120.

DOI: 10.1109/ppc.2011.6191655

[4] Sung-Roc Jang, Hong-Je Ryoo, G. Goussev, Geun Hie Rim: IEEE Trans. on Plasma Science, Vol. 40, Issue 10, PT 1 (2012), p.2561.

DOI: 10.1109/tps.2012.2186592

[5] V. Khanna: Insulated Gate Bipolar Transistor IGBT Theory and Design, ch. 10, Institute of Electrical Engineers (2003).

DOI: 10.1002/047172291x.ch4

[6] Jing Zhu, Qinsong Qian, Weifeng Sun: IEEE International Conference of Electron Devices and Solid-State Circuits (2009), p.103.

DOI: 10.1109/edssc.2009.5394178

[7] Y. Tsuruta, M. Bando, Y. Ito, A. Kawamura: IEEE 41st Industry Applications Conference (2006), p.2144.

[8] H. Mirzaee, S. Bhattacharya, Sei-Hyung Ryu, A. Agarwal: IEEE Electric Ship Technologies Symposium (2011), p.248.

[9] Hyoyol Yoo, Eunyong Shim, Jeabong Kang, Gilyong Choi, Changyo Lee, Byeongsu Bang: IEEE 8th International Conference on Power Electronics and ECCE Asia (2011), p.1572.

DOI: 10.1109/icpe.2011.5944533

[10] A. Huang: IEEE 34th Annual Conference of Industrial Electronics (2008), p.28.

[11] T. Jalakas, D. Vinnikov, T. Lehtla, V. Bolgov: International Conference on Compatibility and Power Electronics (2009), p.438.

[12] M.S. Adzic, E.M. Adzic, V.A. Katic: 14th International Power Electronics and Motion Control Conference (2010), p. T5-52.

DOI: 10.1109/epepemc.2010.5606843

[13] T. Ziemba, K. Miller, J. Prager, J. Carscadden: IEEE Pulsed Power Conference (2011), p.1321.

[14] A. Salih: IEEE 38th Annual Conference of Industrial Electronics (2012), p.3274.

[15] V. Ermel, M. Kurrat, J. Meisner, M. Kahmann: IEEE International Workshop on Applied Measurements for Power Systems (2012), p.1.

DOI: 10.1109/amps.2012.6343990
