A Method for Improving Compensation Performance of the Active Power Filter

Abstract:

Distributed renewable energy connected to the power grid in the form of micro-grid, which makes a great impact on the power quality of the grid. Active Power Filter (APF) is a kind of effective device, which can improve the power supply quality and purify the power pollution. It‘s particularly significant to improve the APF’s performance. Based on the selective harmonic current control strategy, which is used to solve the problem, that the main times of the harmonic current is not sufficiently compensated, this paper considers to adopt the LCL filter on the grid-side to further improve the compensation performance of active power filter. This improvement can reduce the high frequency harmonics caused by the way of PWM high frequency modulation. Finally a case study simulated by PSIM software verifies the superiority of the proposed measure.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1240-1246
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1240
• Online since: August 2013
• Authors: Wei Si Deng, Bu Han Zhang, Hong Fa Ding, Jian Shao, Bing Jie Jin
• Keywords: Active Power Filter (APF), Harmonic Detection, LCL Filter, Microgrids (MGs), Power Quality (PQ), Selective Compensation

References

[1] Wu Jinchang. The harmonics of power system[M]，1998.

[2] Ma Jie, Zhang Jiancheng．Harmonics Measurement and Analysis of Grid-Connected PV System[J]．Power System and Clean Energy，2010，26(11)：112-115.

[3] Hu Min, Chen Heng．Active Power Filter Technology and Its Application[J]．Automation of Electric Power Systems，2000，(03)：66-70.

[4] Yang Yie, Ren Zhen, Tang Zhuorao．A New Method for Harmonics Detection Based on Wavelet Transformation[J] ．Automation of Electric Power Systems，1997，21(10)：39-42.

[5] Li Gengyin, Chen Zhiye, Ding Qiaolin, et al．Definition of Generalized Instantaneous Reactive Power in dq0 Coordinates and Its Compensation[J]．Proceedings of the CSEE，1996，16(3)：176-179.

[6] Li Lanfang, Yang Honggeng, Guo Weiming．Stability control of the three-phase shunt active power filter based on the fuzzy control and Lyapunov theory[J]．Power System Protection and Control，2013，41(2)：150-155.

DOI: 10.1109/appeec.2012.6307617

[7] H. Akagi, Y. Kanazawa, A. Nabae．Instantaneous Reactive Power Compensation Switching Devices without Energy Storage Components [J]．IEEE Transactions on Industry Applications, 1984，IA-20(3)：625-630.

DOI: 10.1109/tia.1984.4504460

[8] Liu Fei, Zha Xiaoming．Design and Research on Parameter of LCL Filter in Three-Phase Grid-Connected Inverter[J]．Transactions of China Electrotechnical Society，2010，25(03)：110-116.

DOI: 10.1109/ipemc.2009.5157762

[9] Liu Weiwei, Ding Hongfa, Duan Xianzhong．Selective Harmonic Current Control Strategy in Active Power Filters[J]．Proceedings of the CSEE，2011，31(27)：14-20.
