A Non-Isolated Buck-Boost Grid-Connected Inverter with no Shoot-Through Problem

Abstract:

The grid-connected inverters required for distributed generation systems should have high reliability. However, a shoot-through problem, which is a major killer of the reliability of the inverters, exists in the conventional bridge-type voltage-source inverters. In order to solve the aforementioned problem, a non-isolated buck-boost grid-connected inverter with no shoot-through problem is proposed. The hysteresis current control is used. The output voltage of the proposed grid-connected inverter can be larger or lower than the input voltage. The operating principle is illustrated. Simulation verifies the theoretical analysis.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 1247-1250
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.1247
• Online since: August 2013
• Authors: Zhi Lei Yao, Jia Rong Kan, Guo Wen Hu
• Keywords: Buck-Boost, Grid Connected, Hysteresis Current Control, Inverter, Non-Isolated

References

[1] Y. Xue, L. Chang, S. B. Kjaer, J. Bordonau and T. Shimizu: IEEE Trans. Power Electron. vol. 19 (2004), p.1305–1314.

DOI: 10.1109/tpel.2004.833460

[2] S. B. Kjaer, J. K. Pederson and F. Blaabjerg: IEEE Trans. Ind. Appl. vol. 41 (2005), p.1292–1306.

[3] G. Buticchi, E. Lorenzani and G. Franceschini: IEEE Trans. Ind. Electron. vol. 60 (2013), p.906–918.

DOI: 10.1109/tie.2012.2189538

[4] Z. Yao and L. Xiao: IEEE Trans. Power Electron. vol. 27 (2012), p.3310–3318.

[5] Z. Yao, L. Xiao and Y. Yan: IEEE Trans. Power Electron. vol. 25 (2010), p.1597–1603.

[6] J. Almazán, N. Vázquez, C. Hernandez, J Álvarez, J. Arau: IEEE CIEP, vol. 1 (2000), p.341–346.

[7] F. Z. Peng: IEEE Trans. Ind. Appl. vol. 39 (2003), p.504–510.

[8] Z. Zhou, X. Zhang, P. Xu and W. X. Shen: IEEE Trans. Ind. Electron. vol. 55 (2008), p.2997–3004.
