Hysteresis Modeling and Inverse Feedforward Compensation for PZT Actuator in Dual-Stage Hard Disk Drive

Abstract:

With the growth of hard disk storage, it would be difficult to meet the specification of the high track density with conventional single actuator. Therefore the next generation of high speed hard disk drive uses the concept of dual-stage actuated hard disk drive where a secondary actuator is mounted onto the VCM actuator. This helps to achieve higher servo bandwidth and, therefore, more precise tracking. Improved tracking error allows higher track density and hence higher storage capacity. Piezoelectric actuator has been a popular choice as the secondary stage. However, the piezoelectric actuators exhibit an unavoidablecharacteristic of hysteresis which causes inaccuracies and oscillations in the system responses.In this paper, the hysteresis behaviour is investigated for asuspension based PZT actuator which is used as the secondary actuator of HDD available in the market. The Generalized Prandtl-Ishlinskii (GPI) hysteresis model which is a phenomenological based model is obtained usingnon-linear least square curve-fitting. In the secondexperiment, a second order linear dynamics model of the PZT actuator is obtained using frequency response identificationmethod. High frequency resonance modes of the PZT actuator are eliminated using a notch filter. By integrating the obtained GPI hysteresis model with this second-order lineardynamics, a nonlinear dynamic model and an inverse feedforward controller are developed.Preliminary simulation results demonstrate that inverse feedforward controller can be appliedfor precise tracking of triangular and multiple frequency sinusoidal trajectories.

• Periodical: Advanced Materials Research (Volume 740)
• Pages: 152-158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.740.152
• Online since: August 2013
• Authors: Md. Arifur Rahman, Poh Wee Han, Abdullah Al Mamun
• Keywords: GPI, HDD, Hysteresis, Inverse Feedforward, Inverse GPI, PZT

References

[1] R.C. Smith, Smart Material System: Model Development, society for Industrial and Applied Mathematics (2005).

[2] I.D. Mayergoyz, Mathematical Models of Hysteresis, New York, Elsevier (2003).

[3] M. Brokate and J. Sprekels, Hysteresis and Phase Transitions, New York, Springer (1996).

[4] G. Tao and P. V. Kokotovic, Adaptive control of plant with unknown hysteresis, IEEE Transactions on Automatic Control, vol. 40 (1995),pp.200-212.

DOI: 10.1109/9.341778

[5] X. Chen and T. Hisayama, Adaptive sliding-mode position control for piezo-actuated stage,IEEE Trans. Ind. Electron., vol. 55 (Nov. 2008), no. 11,p.3927–3934.

DOI: 10.1109/tie.2008.926768

[6] M. Al Janaideh, J. Mao, S. Rakheja, W. Xie, and C-Y Su, Generalized Prandtl-Ishlinskii hysteresis model: Hysteresis modeling and its inverse for compensation in smart actuators, in Proc. IEEE Conf. Decis. Control, Cancun, Mexico (2008), p.5182–5188.

DOI: 10.1109/cdc.2008.4739202

[7] J.Yi, S.Chang, andY. Shen, Disturbance-observer-Based hysteresis compensation for piezoelectric actuators,IEEE/ASME Trans. Mechatronics, vol. 14 (Aug. 2009), no. 4, p.456–464,.

DOI: 10.1109/tmech.2009.2023986

[8] Y. Shan, J. Speich, and K. Leang, Low-cost IR reflective sensors for submicrolevel position measurement and control,IEEE/ASME Trans.Mechatronics, vol. 13 (Dec. 2008), no. 6, p.700–709.

DOI: 10.1109/tmech.2008.2005407

[9] K. Leang, Q. Zou, and S. Devasia, Feedforward control of piezoactuators in atomic force microscope systems: Inversion-based compensation for dynamics and hysteresis,IEEE Control Syst. Mag., vol. 19 (Feb. 2009), no. 1, p.70– 82.

DOI: 10.1109/mcs.2008.930922

[10] A. Visintin, Differential Models of Hysteresis. Berlin, Germany: Springer-Verlag (1994).

[11] W. Galinaities, Two methods for modeling scalar hysteresis and their use in controlling actuators with hysteresis, Ph.D. dissertation, Dept. Math., Blacksburg, Virginia, USA(1999).

[12] Y.Z. Tan, C.K. Pang, Fan Hong, Sangchul Won, and T.H. Lee; Hysteresis Compensation of Piezoelectric Actuators in Dual-Stage Hard Disk Drives, Proceedings of 2011 8th Asian Control Conference (ASCC), Kaohsiung, Taiwan (May 15-18, 2011).

[13] S. Nakamura, H. Numasato, K. Sato, M. Kobayashi, and I. Naniwa, A Push-Pull Multi-Layered Piggyback PZT Actuator, Microsystem Technologies, Vol. 8 (2002), No. 2–3, p.149–154.

DOI: 10.1007/s00542-002-0180-z
