The Spindle Component Analysis of Inner Cavity Shaping Machine Tool

Abstract:

This paper takes the spindle of inner cavity shaping machine tool as the research object, analyzes the spindle structure of the machine tool and establishes the equations of motion, analyzes the influence that the spindle speed and tool deflection speed have on the tool rotary speed using Matlab and ADAMS, determines the allowed deflection range of the tool, sets up the transfer function of the servo motor current loop and analyzes the stability of spindle servo motor current loop .

• Periodical: Advanced Materials Research (Volume 740)
• Pages: 170-177
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.740.170
• Online since: August 2013
• Authors: Zai Jin Wang, Qiang Li
• Keywords: Analysis of Spindle Component, Current Loop Transfer Function, Equation of Motion, Inner Cavity Grain

References

[1] Wen Xisen, Qiu Jing, Tao Junyong, Analyzing Dynamics and Application of Electrical and Mechanical System. Science Press, (2003)

[2] MDI Company, Advanced ADAMS/View Training Guide.

[3] Xie Chuanfeng, Dynamics[M]. the second edition. Beijing: Higher Education Press, 2004.

[4] Karnopp, D., Margolis, D. and Rosenberg, R., System Dynamics: Modelling and Simulation of Mechatronic Systems[M], Wiley, New York, 2000.

[5] Marcus S. and John M., Dynamic Modeling of Electromechanical Multibody Systems[J], Multibody System Dynamics 9: 87~115, 2003.
