The Design of Constant Pressure Water Supply Control System Based on S7-200 PLC

Abstract:

IN tall buiding’s constant pressure water supply system with PLC and frequency converter logic control, PLC is used for logic control and frequency converter for pressure regulation . PLC and frequency converter which are the core components of the system track changes on the deviation of the pressure in a pipe with the given pressure,through the PLC internal PID operational, it can control variable frequency and power frequency switching and automatic control the number of inputting pumps and speed of the motor to realize closed loop automatic regulation voltage variable water supply, It can achieve the purpose of controlling the flow of water while maintaining constant pressure.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 1665-1669
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.1665
• Online since: August 2013
• Authors: Man Rong Xing, Jie Zhang, Xiao Dong Zhang
• Keywords: Constant Pressure Water Supply, Frequency Conversion Speed Regulation, Programmable Logic Controller (PLC)

References

[1] Wei Li, Yingbao Zhao, Liu Zhaoying: PLC used in constant-pressure water supply system [ A]. Chinese Association of automation in the Ninth National automation new technology academic conference Set [ C], 2004, In Chinese.

[2] Yongwei Li: new model of variable frequency speed regulation constant pressure water supply system Based on the PLC [ M]. Beijing: Mechanical Industry Press, 2004, In Chinese.

[3] Lingfang He. automatic frequency constant pressure water supply system Based on PLC control [J]. Xi'an Institute of science and technology, 2000, 20(3): 243-245, In Chinese.

[4] Quan Tao, Ruilu Wei : PLC control system design, installation and debugging, Beijing: Beijing Institute of Technology press, 2011, 163-185, In Chinese.
