Design of Monitor and Control System of Screw Pump Oil Production Based on ATT7022

Abstract:

Design a working condition monitoring and intelligent diagnosis system for screw pump based on the ATT7022 chip. Achieve real-time acquisition, storage, analysis of the driving motor electrical parameters of three-phase voltage, current, frequency, active and inactive power, power factor, and the fluid parameters of screw pump production well pressure, pressure, temperature. Accomplish monitoring, alarm and automatic protection the screw pump failure of rod breaking, pump sticking, vacuum, lack of power phase. Using PIC microprocessor to automatic compensate the screw pump motor power, to improve the work efficiency.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 2145-2148
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.2145
• Online since: August 2013
• Authors: Chun Yu Xiong, Feng He Qi, Zong Guang Guo, Yun Bo Xia
• Keywords: ATT7022, Cavity Pump, Reactive Power Compensation, Working Condition Monitoring

References

[1] Huan Wang, Xianfeng Wei, Yunfei Li, Jiqian Wang, Linqi Wang, Songfang Cheng: Oil-Gasfield Surface Engineering. Vol. 1(2008), p.29, In Chinese.

[2] Zhenzhong Dou: PIC MCU design principles and procedures (Beihang University Press, Beijing 1998), In Chinese.

[3] Actions Inc. ATT7022B Datasheet. (2005).

[4] Lei Yang, Guangming Huang: Electrical Measurement & Instrumentation. Vol. 5(2007), p.62, In Chinese.

[5] Wei Weng, Zhijie Zhu, Junjie Chen, Yaojun Wen: Low voltage apparatus. Vol. 21(2009), p.30, In Chinese.
