Research of CAPP System Based on the Solid Edge

Abstract:

The three-dimensional CAPP prototype is studied based on Solid Edge platform using the technology of secondary development of VB. The system is able to complete part the selection of machining feature of the part, edit of process information and selection of process. The system finally output process card semi-automatic or automatic, through the module of process edit and the module of process card output module having the support of the process resource management module.

• Periodical: Advanced Materials Research (Volumes 765-767)
• Pages: 167-170
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.765-767.167
• Online since: September 2013
• Authors: Jiang Tao Cui, Guo Qiang Shen
• Keywords: 3D-CAPP, Database, Solid Edge, System Development

References

[1] Buyun Sheng. Study and Practice on CAPP Software Component Base on 3D Platform. Machinery. 2007, (4): 20-22.

[2] Xinxin Liu . CAPP System Process Management Research. Modern Manufacturing Technology and Equipment. 2007, (5) : 58-59.

[3] Li Sun. Research on the Key Techniques of CAPP Database. Machine Building &Automation. 2007, 36(5): 23-25.

[4] Zheng Xu. Study and Practice of CAD/CAPP integrated method in 3D Environment. Machinery Design & Manufacture. 2005, (8): 55-57.

[5] Zongshun Chen. machinery manufacturing process design and CAPP technology [M] Beijing: Tsinghua University Press, (2004).

[6] Rujia Zhao. aided process planning (CAPP) [M]. Beijing: Machinery Industry Press, (2003).
