Development and Application of Virtual Manufacturing Technology

Abstract:

As an advanced machining technology, virtual manufacturing has been regarded as an useful tool to carry out analysis and research work with digital model instead of practical manufacture. For the virtual manufacturing process, it is a mapping of the practical machining in computer virtual environment, no real production is created and without material or power wasting. Several typical definition of virtual manufacturing dominate in this fields were listed out, based on which expressed an explicit interpretation. Main features and three type of virtual manufacturing, such as design-centered, machine-centered and control centered virtual manufacturing were analysed respectively. The virtual manufacturing system, supported by cutter tool magazine, pallet storage, production database, material storage and NC storage, have been demonstrated in an architecture figure. Finally, the author concluded the important role of virtual manufacturing and illustrated an example of applying virtual manufacturing in five-axis machining process.

• Periodical: Advanced Materials Research (Volumes 765-767)
• Pages: 151-155
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.765-767.151
• Online since: September 2013
• Authors: Xiao Jing Li, Cheng Si Li
• Keywords: Advanced Manufacturing Technology, Simulation, Virtual Manufacturing

References

[1] Kazuaki Iwata, Masahiko Onosato, Koji Teramoto. Virtual Manufacturing Systems as Advanced Information Infrastructure for Integrating Manufacturing Resources and Activities, CIRP Annals - Manufacturing Technology. Vol 46, (1997)P335-338.

DOI: 10.1016/s0007-8506(07)60837-3

[2] Shao Li, Chung Ting-Xiu. Virtual manufacturing and its application. Shanghai Jiaotong University, 1999, 33 (7): 906 - 911.

[3] Yi Hong, Wen-Cheng Tang, et al. Workshop agile virtual environment research Manufacturing Automation, 2000, 22 (2). 21 - 24.

[4] Chou Xiaoli, Wu Xiying. Virtual manufacturing technology to enhance the level of manufacturing plant [J]. Manufacturing Automation, 2000, 22.

[5] Leo J. De Vin, Magnus Holm, Amos H.C. Ng. The Information Fusion JDL-U model as a reference model for Virtual Manufacturing, Robotics and Computer-Integrated Manufacturing. Vol 26, (2010)P 629-638.

DOI: 10.1016/j.rcim.2010.07.002

[6] K.I. Lee, S.D. Noh. Virtual Manufacturing System—a Test-Bed of Engineering Activities, CIRP Annals - Manufacturing Technology. Vol 46, (1997)P347-350.

DOI: 10.1016/s0007-8506(07)60840-3
