Quadratic Hilbert Transform Demodulation Based on Time-Delayed Correlation Treatment and EEMD

Abstract:

To deal with the demodulation problem of rolling bearing defect vibration signal in heavy noise, a new method based on time-delayed correlation algorithm and ensemble empirical mode decomposition (EEMD) is presented. Introduced the time-delayed autocorrelation de-noising principle. After the discretization and unbiased estimation of the original signals autocorrelation function , de-noising pretreatment is implemented by appending a rectangle window. Then an envelope signal can be obtained by the first Hilbert transform. After the EEMD decomposition, some interested intrinsic mode functions (IMFs) can be collected. By making the second Hilbert transform of the IMFs, we can get the local Hilbert marginal spectrum from which the defects in a rolling bearing can be identified. By repeated analysis of simulation signals and actual rolling bearings defect vibration signal, the results show that the proposed method is more effective than direct modulation or only time-delayed correlation demodulation or combine time-delayed correlation with EMD demodulation in de-noising and diagnosing the rolling bearing's defect information.

• Periodical: Advanced Materials Research (Volumes 765-767)
• Pages: 2715-2719
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.765-767.2715
• Online since: September 2013
• Authors: Qing Xiong, Wei Hua Zhang, Gui Ming Mei
• Keywords: Delayed Correlation, Demodulation, Ensemble Empirical Mode Decomposition (EEMD), Hilbert Transform, Local Hilbert Marginal Spectrum

References

[1] Tao Meng, Mingfu Liao: Detection and Diagnosis of the Rolling Element Bearing Fault by the Delayed Correlation-Envelope Technique . Vol. 25 (2004), p.41.

[2] Hui Sun, Shanan Zhu: Hilbert-Huang transform demodulation based on delayed autocorrelation pretreatment . Vol. 30 (2005), p. (1998).

[3] Zhaohua Wu, N E Huang: Ensemble empirical mode decomposition: a noise-assisted data analysis method. Vol. 1 (2009), p.1.

[4] Chao Zhang, Jianjun Chen. Contrast Of Ensemble Empirical Mode Decomposition and Empirical Mode Decomposition in Modal Mixture. Vol. 29 (2010), p.87.

[5] Yaguo Lei: Machinery Fault Diagnosis Based on Impr oved Hilbert-Huang Transform. Vol. 47 (2011), p.71.

[6] Dejie Yu, Junsheng Cheng, Yu Yang: Application of the Hilbert-Huang Transform Method to Roller Bearing Fault Diagnosis. Vol. 14 (2003), p.2140.

[7] Information on http: /csegroups. case. edu/bearingdatacenter/home.
