Harmonic and Power Factor Analysis with Reactor and Capacitor in Adjustable Speed Drive

Abstract:

Ac line reactor, Dc link reactors and shunt capacitors are mostly used for improving the power factor and reducing the THD level in the adjustable speed drive (ASD) and protecting the device from other power quality problem. The effectiveness of these reactors are affected by many other factors such as loading and source impedance. Under variable load conditions such factors are analyzed and performance of system also analyzed. In this paper simulation is done by inserting such factor which also suggested for future real time applications.

• Periodical: Advanced Materials Research (Volume 768)
• Pages: 317-322
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.768.317
• Online since: September 2013
• Authors: M. Srinivasan, S.U. Praba, R. Suganthi
• Keywords: AC Line Reactor, DC Link Reactor, Input Harmonics, Power Factor, Shunt Capacitor, Source Inductance

References

[1] xiaodong liang, obinna ilochonwu, and jeffrey lim, influence of reactors on input harmonics of variable frequency drives vol. 47, no. 5, september/october 2011, pp.2195-2197.

DOI: 10.1109/tia.2011.2161858

[2] Electromagnetic Compatibility (EMC)—Part 3–6: Limits—Assessment of Emission Limits for the Connection of Distorting Installations to MV, HV and EHV Power Systems, IEC/TR 61000-3-6: 2008, Apr. (2008).

DOI: 10.1109/ieeestd.2012.6232421

[3] Milton E. de Oliveira Filho, Jonas R. Gazoli, Alfeu J. Sguarezi Filho, Ernesto Ruppert Filho A Control Method for Voltage Source Inverter Without Dc Link Capacitor, 2008 IEEE vol. 978-1-4244-1668-4/08.

DOI: 10.1109/pesc.2008.4592660

[4] K. Lee, T. M. Jahns, T. A. Lipo, G. Venataramanan, and W. E. Berkopec, Impact of input voltage sag and unbalance on dc-link inductor and capacitor stress in adjustable-speed drives, IEEE Trans. Ind. Appl., vol. 44, no. 6, p.1825–1833, Nov. /Dec. (2008).

DOI: 10.1109/tia.2008.2006308

[5] F. W. Fuchs and A. Kloenne, DC link and dynamic performance features of PWM IGBT current source converter induction machine drives with respect to industrial requirements, in Proc. 4th IPEMC, 2004vol. 3, p.1393–1398.

[6] D. Detjen, J. Jacobs, R. W. De Doncker, and H. -G. Mall, A new hybrid filter to dampen resonances and compensate harmonic currents in indus- trial power systems with power factor correction equipment, IEEE Trans. Power Electron., vol. 16, no. 6, p.821– 827, Nov. (2001).

DOI: 10.1109/63.974380

[7] R. Sladky, T. Gilmore, G. Frazier, and D. Jaszkowski, Distribution system disturbances and its effects on voltage source inverter drives, Rockwell Automation, Standard Drives Business Unit, Power Group, Allen-Bradley Co., Jul. 18, (1995).

[8] IEEE Recommended Practices and Requirements for Harmonic Control in Electrical Power Systems, IEEE Std. 519-1992, (1993).

[9] F. W. Fuchs and A. Mueller-Hellmann, Control methods for reducing the inductance in the dc link of current source inverters, IEEE Trans. Ind. Appl., vol. 1A-19, no. 5, p.699–707, Sep. /Oct. (1983).

DOI: 10.1109/tia.1983.4504278

[10] M. Hombu, S. Ueda, and A. Ueda, A current source GTO inverter with sinusoidal inputs and outputs, IEEE Trans. Ind. Appl., vol. IA-23, no. 2.

DOI: 10.1109/tia.1987.4504899
