Effect of Rolling Direction to the Strength of a Thin-Walled Steel SHS Beam under Concentrated-Compressive Load and Bending Moment

Abstract:

In this research, it has been carried out the development of a strength analytical method of a thin-walled steel square pipe (Square Hollow Section/SHS) affected by the interaction of concentrated-compressive load and bending moment then it verified by experimental approach. The experimental approach was consisted of measuring a basic material property and the strength of the investigated SHS pipe. The basic material property identified parallel to rolling direction (0^o) and perpendicular to rolling direction (90^o). The analytical data obtained from cut-off strength method is generally scattered within the acceptable limits of ± 20 % and tends to be in unconservative region. The actual data measured from experiments shows that SHS beam with t = 0.6 mm and longitudinal axis parallel to the rolling direction of base material has higher strength compared to the one of the SHS beam with t= 0.6 mm and longitudinal axis perpendicular to the rolling direction, meanwhile the SHS beam with t= 1.2 mm is tends to be equal. This means that the rolling direction of base material can be considered to be a parameter in the strength design of a thin-walled SHS beam

• Periodical: Advanced Materials Research (Volume 789)
• Pages: 398-402
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.789.398
• Online since: September 2013
• Authors: Andi M. Kadir, Dedi Priadi, Eddy S. Siradj, Harkali Setiyono
• Keywords: Cut-Off Strength, Plastic Mechanisms, Rolling Direction, SHS Beam, Strength Analytical, Thin-Walled Steel

References

[1] Kadir M. Andi, et al, Strength Analysis of a Thin-Walled Steel Square Hollow Section Beam Affected by the Interaction of Concentrated-Compressive Load and Bending Moment , Quality in Research (QIR), University of Indonesia, (2011).

DOI: 10.14203/metalurgi.v28i1.244

[2] Norman E. D., Mechanical Behaviour of Material, Engineering Methods for Deformation , fracture, and Fatigue , Prentice-Hall International Edition, USA, (1993).

[3] Harkali Setiyono, Web crippling of cold-formed plain channel steel section beams, PhD Thesis, University of Strathclyde, August, (1994), pp.199-232.

[4] Bakker, M.C.M. Yield line analysis of post-collapse behavior of thin-walled steel members, Heron, Vol. 35, No. 3, (1990), pp.3-50.

[5] Harkali Setiyono, The Development of a combined plastic mechanism and elastic-analytical model to estimate the moment capacity of a thin-walled channel steel section, Proceedings - The 11th International Pacific Conference (IPC 10) on Automotive Engineering, Shianghai-China, November 6-9, (2001).

DOI: 10.56748/ejse.658

[6] Harkali Setiyono, Plastic mechanisms and elastic analysis in the strength estimation of an axially compressed thin-walled channel steel section beam, Electronic Journal of Structural Engineering (eJAE International), June, (2006).

DOI: 10.56748/ejse.658

[7] Harkali Setiyono, An Alternative Approach to the Analytical Determination of the Moment Capacity of a Thin-Walled Channel Steel Section Beam, International Journal of Mechanical Sciences, Vol. 50, August, (2008).

DOI: 10.1016/j.ijmecsci.2008.05.004

[8] Murray, N.W. and Khoo, P.S., Some basic plastic mechanisms in the local buckling of thin-walled steel structures, International Journal of Mechanical Sciences, Vol. 23, No. 12, (1981), pp.703-713.

DOI: 10.1016/0020-7403(81)90008-4

[9] W.D. Callister JR, Material Science and Engineering An Introduction, John Wiley & Sons Inc, (1991).

[10] Japanese Standards Association, JIS Handbook – ferrous materials & metallurgy I, (2009).

[11] M.F. Ashby, Material Selection in Mechanical Design, Second Ed. (1999).
