Analysis of Micro-Channels Manufacturing of Acrylic Using Low Power CO₂ Laser

Abstract:

Several studies have demonstrated the ability of laser for micro-channels fabrication. There are some important aspects that must be considered to use laser for machining process, such as machining method, type of laser and interaction between laser and workpiece. In this research, CO2 laser machine was used as a tool to fabricate a micro-channes on acrylic. Some parameters that can influence the outcome of the cuts were setup, which are focus distance on Z axis, laser power, cutting speed, and the repetition of cutting process (number of pass). Cutting results were width and depth of cut. Observation was made by using digital microscope as measuring tool, and measurement result was analyzed by using Anova method. The results of the analysis shows that the parameter of laser power has a dominant influence on depth of cut, and then parameter of cutting speed and number of pass. By determining width and depth of the cut based on given parameters, it will be easier to take a shape and size on micro-channel fabrication.

You might also be interested in these eBooks

Advances in Materials, Processing and Manufacturing

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 789)

Pages:

408-411

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.789.408

Citation:

Cite this paper

Online since:

September 2013

Authors:

Ario Sunar Baskoro, Agus Siswanta, K.G.S. Ismail

Keywords:

Acrylic, ANOVA, CO₂Laser, Micro-Channel, Number of Pass

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Nayak NC, Lam Y, Yue C, Sinha TA: J Micromech. Microeng vol. 18 (2008), p.095020.

Google Scholar

[2] T.D. Boone, Z.H. Fan, I. Gibbons, A.J. Ricco, H. Tan, S.J. Williams: Anal. Chem., Plastic Advances Microfluidics Devices, Vol. 74(2002), p. 78A.

Google Scholar

[3] Gartner C, Klemm R, BeckerH: Methods and instruments for continuous-flow PCR on a chip in: Proc. SPIE. Microfluidicss BioMEMS and Medical microsystems V, SanJose, USA, January 22, (2007), p.1.

DOI: 10.1117/12.713797

Google Scholar

[4] Hashimoto M, Chen PC, Mitchell MW, Nikitopoulos DE, Soperb SA, Murphy MC: Lab Chip Vol. 4 (2004), p.638.

Google Scholar

[5] Devalckenaere M, Jadin A, Kolev K, Laude LD: Nucl Instrum Methods B Vol. 151 (1999), p.263.

Google Scholar

[6] Dahotre, Narendra B dan S. P. Harimkar: Laser Fabrication and Machining of Material, Springer Science + Business Media, LLC (2008).

Google Scholar

[7] M. Bowden, O. Geschke, J. P. Kutter and D. Diamond: Lab Chip Vol. 3(2003), p.221.

Google Scholar
