Vane-Turbine as an Energy Conversion in the Propeller Slipstream of Single Screw Ship

Abstract:

The screw propeller of a ship generates thrust to make it moving. As a propeller rotates, it draws fluid into itself from the surrounding area (slipstream). The propeller produces two types of flow behind it, accelerated and circulated flows. Some of the energy from the ship engine is lost in the accelerated flow behind ship as a jet wash.The kinetic energy losses in the slipstream propeller captured by a turbine called the propeller-turbine system. This composed screw propeller of a vessel (the main propeller) and a vane turbine that is the area of vanes located inside the wake of the main propeller. It recovers the energy generated by the main propeller pushing water back out (which would be otherwise wasted behind the main propeller) and hopefully enhancing the efficiency of the main propeller.The influence of vane turbine on the performance breakdown of single screw ships were analyzed by using 5 (five) ships . Ship powering was calculated by using DESP Code 10 software. Thrust and power of vane turbine were calculated by applying actuator disc theory. Although the vane turbine affected speed loss of the ship, the power efficiency gained to be found always positive. Vane turbine is suitable as an energy saving device of the single screw ship.

• Periodical: Advanced Materials Research (Volume 789)
• Pages: 417-422
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.789.417
• Online since: September 2013
• Authors: S. Leksono, I Ketut Aria Pria Utama, Ma Djoni, Wasis Dwi Aryawan
• Keywords: Efficiency-Gained, Energy-Slipstream, Propeller-Turbine, Speed Loss

References

[1] F. Celik, M. Guner: Energy saving device of stator for marine ( Ocean Eng., 34, Elsevier, 2007), pp.850-855

[2] C. Kee , G.E Hamill, W.H Lam, P.W Wilson : Investigation of the velocity distribution within a ship's propeller wash ( Proceeding of the Sixteenth IOPEC, San Francisco, California, USA, 2006)

[3] E.J Glover: Propulsive devices for improved propulsive efficiency (Trans. Institute of Marine Engineers, London, vol. 99, paper 31), pp.23-29

[4] A.S Olsen : Energy coefficient for a propeller series ( Elsevier,Ocean Eng.31, 2004), pp.401-416

[5] B.Y. Chen, A.M Reed, K.H Kim : A Vane-wheel propulsor for a naval auxilliay, ( DTRC - 89/023 , 1989)

[6] - : Simplified prediction of propeller inflow/outflow properties ( A Hydrocom Technical Report, No 129, 2003)

[7] Holtrop J: Design of propulsor (Hydrodinamiscs course of ship propulsion,MARIN, Wageningen, 2001)

[8] D. Hartwanger, A. Horvat: 3D Modelling of wind turbine using CFD, (NAFEMS Conference, UK, 2008)

[9] F.D Bianchi, H.de Battista, R.J Mantz: Wind turbine control systems, Principles, Modelling and Gain Scheduling Design ( Springer XIX, 2007)

DOI: 10.1002/rnc.1263

[10] E.V Nastase, D Scurtu, D Calarasu D, B Ciobanu : Design methodology of kinetic Hydraulic Turbines ( IJMMT,Vol III, No.1, 2011)
