Design of Control System in Strapping Machine for Paper Bills

Abstract:

The strapping machine for Paper Bills typically was designed to reduce labor intensity and enhance production automation level. The machines structure and working principle were described. There are three work posts in this equipment, they work continuously. This approach makes it very easy to split up a complex transformation into a series of simple transformations arranged in a loop line. The machine includes currency count/counterfeit distinguishing system, conveying system and strapping system. In the same time, the machine control system that adopts the PLC programmable controller can simplify the control system, and its reliability strengthens further. Practices show that the strapping machine has the advantages of simple structure, high efficiency, low cost and small vibrating noise.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 603-606
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.603
• Online since: September 2013
• Authors: Xin Ju Zhang, Xiu Hong Ma
• Keywords: Paper Bill, Programmable Logic Controller (PLC), Strapping Machine

References

[1] Huang Cheng-nan. The Present Situation and the Development Strategy of Chinese Strapping Machine [J]. China Packaging Industry. 1998 (10) 6～8.

[2] Zhang Ji-hong. Concentration on Machatronics Technology used in Design of Machaging Machinery [J]. Package Engineering. 2002 (6) 159～162.

[3] Song Yu-qin. Development and Tentative Ideas about the pneumatic Bundling Machine with Steel Belt [J]. Package Engineering. 1993 (1) 31～34.

[4] Yang Miao, Cao Ju-jiang and Li Zhi-ming. Design of Environment-friendly Glue Conveying and Heatseal Mechanism of Binding Machine [J]. Package Engineering. 2010 (1) 65～67.

[5] Li Xiao-xing, Dang Xin-an and Qian De-ming etc. Study of the Bonding Properties of Paper Banding Strip [J]. Package Engineering. 2010 (1) 13～16.

[6] Li Xiao-xing and Qian De-ming. The Design and Research of Environmental-Friendly Binding Machine [J]. Journal of Zhejiang Industry & Trade Vocational College. 2010（3）71～75.

[7] Lin Jin-biao and Zhang Zi-wu. The Design of Delivering-settling Mechanism in JUST - I Fully Automatic Control Large Packing Paper Money Machine [J]. Journal of Jimei University Natural Science. 2003 (4) 350～352.

[8] Yang Yi-ping, Yue Yan-fang and Yang Guang. Design and Research of the 49s/SMD Crystal Automatic Forming Machine [J]. Manufacturing Automation. 2009 (7) 115～117.
