Hardware System for Automotive Wiring Harness Testing Based on DAQ Instrument

Abstract:

With the development platform based on Advantech DAQ board, we have completed the design of multi-channel analog switch, decoding circuit and impedance testing circuit and built a good hardware platform for the automotive wiring harness testing system. Testing software is used to import different values into the digital I/O of data acquisition card of the hardware of to choose the tested points and then the voltage signal is read from every loop and the voltage signal is sent into the computer. Analyzing, processing, displaying is done by the testing software so that the hardware system becomes the development platform for Lab-VIEW software application.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 971-974
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.971
• Online since: September 2013
• Authors: Wei Dong Feng, Ji Hui Pan, Wen Xu
• Keywords: DAQ, Decoding Circuit, Impedance Testing, Wiring Harness

References

[1] H. Goldberg. What is virtual instrumentation. Instrumentation & Measurem-ent Magazine, IEEE, Pages 10-13, Vol3, No4, Dec. (2000).

[2] Yi Niandong, Virtual Iinstrument and Technique Research, Journal of Zhejiang University, Period 6, Volume 34, June (2000).

[3] Yang Leping and Li Haitao, Virtual Instrument Technology Introduction – Beijing: Electronic Industry Press, Mar. (2003).

[4] Advantech Co., Ltd. User's Manual for PCI-1730, printed in Taiwan, June (2001).

[5] Advantech Co., Ltd. User's Manual for PCI-1710 Series, printed in Taiwan, June.

[6] Lei Zhenshan, Practical Technology Course to LabVIEW 7 Express – Beijing: China Railway Publishing House, (2004).

[7] Wang Minsheng, etc, Fundamental Course of LabVIEW – Beijing: Electronic Industry Press, Jan. (2002).

[8] Ma Mingjian and Zhou Changcheng, Data Acquisition and Processing Technology – Xi'an: Xi'an Jiaotong University Press, July. (2001).
