Software System for Automotive Wiring Harness Testing Based on Virtual Instrument

Abstract:

Development of modern information technology provides a technical platform for the wide application of virtual instrument technology. Here we apply virtual instrument technology to test the faults of wiring harnesses, such as short circuit , broken circuit , wiring error , poor contact, poor insulation and unsatisfactory impedance and monitor the product quality at real-time. We use LabVIEW of the graphical programming language based on virtual instrument as the tool to develop the testing software. It realizes the functions such as the data acquisition, storage, analysis and display, single point wiring harness testing, all wiring harness testing, impedance testing, query and statistics, etc. We uses software instead of hardware so that functions can be added or cut down at random without adding any other hardware facilities.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 954-957
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.954
• Online since: September 2013
• Authors: Wei Dong Feng, Wen Xu, Xian Hong Wang
• Keywords: Database, LabVIEW, Query, Virtual Instrument (VI), Wiring Harness

References

[1] Shi Xinwei, The Development Trend of Automotive Wiring Harnesses, Automotive Electronics Supplement, Manufacturing and Equipment of Automobile, Aug. (2005).

[2] Zhang Weihong, Design of Automotive Lamp Wiring Harnesses, Automotive Electric Apparatuses, Henan, Period 11, (2006).

[3] Yang Fenwei, The Application of New Type Wiring Harness Continuity Testing Instrument, Electro-mechanical Components, Shanghai Academy of Spaceflight Technology, No. 808 Institute, Period 1, Volume 22, Jan. (2003).

[4] Zhang Xu, The Reliability Design for Automotive Harness Test Table, Electronic Product Reliability and Environmental Testing, Apr. (2003).

[5] Liu Hua and Mao Ning, Research on Process Information System based on Web for Automobile Wiring Harness Industry, Manufacturing Industry Informatization, Period 5, Volume 18, Sep. (2005).

[6] Zeng Ming. Application Research on Signal Processing Method and Testing System Based on Virtual Instrument Platform, Central South University, Master's Thesis, Changsha, Hunan, Mar. 14th (2003).

[7] Wang Minsheng, etc, Fundamental Course of LabVIEW, Beijing, Electronic Industry Press, Jan. (2002).

[8] Lei Zhenshan, Practical Technology Course of LabVIEW 7 Express – Beijing, Railway Publishing House, (2004).
