Micro-Grooving of Glass Using Small-Diameter Diamond Grindstone with Ultrasonic Vibration

Abstract:

The purpose of this study was to achieve grooving on glass substrates with high levels of efficiency and precision with the use of a diamond grindstone with a small diameter in the range of 1.0-1.8 mm. Mechanical material removal by grinding has high efficiency and enables process control for creating complicated forms, but has a drawback of generating chippings on the processed surface of the brittle glass material. The study gave ultrasonic vibration of 10 μm at 20 kHz in the thrust direction to the rotating small-diameter diamond grindstone in the grinding process, in order to attain high levels of efficiency and precision in micro-grooving of glass. The grooving approach with ultrasonic vibration did create some minor chippings, but succeeded in meeting the target of reducing the average size of chippings around the groove to 0.1 mm or less.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 368-373
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.368
• Online since: September 2013
• Authors: Shigeomi Koshimizu, Shigeru Aoki
• Keywords: Chipping, Glass, Micro-Grooving, Ultrasonic Vibration Assisted Grinding

References

[1] Shigeomi. Koshimizu: Ultrasonic Coring of Glass Disks Using Double Core Drill, Advanced Materials Research, Vols. 325, (2011) pp.436-441.

DOI: 10.4028/www.scientific.net/amr.325.436

[2] Shigeomi. Koshimizu: Ultrasonic Vibration Assisted Drilling of Fine Ceramics, Advances in Abrasive Technology, Vol. 7, (2004), pp.545-548.

[3] E. Uhlmann, G. Spur and S.E. Holl: Machining of Complex Contours by Ultrasonic Assisted Grinding, Technical Paper, Society of Manufacturing Engineers, MR99-284, (1999).

[4] Jianxin Zheng and Jiawen Xu: Basic Experimental Research on NC-Contour Evolution Ultrasonic Assisted Grinding Ceramics Blade Surface, Key Engineering Materials, Vols. 359-360, (2008), pp.369-373.

DOI: 10.4028/www.scientific.net/kem.359-360.369

[5] K. Shimada et al: Ultrasonic-assisted micro-grinding with electroplated diamond wheels, J. Jpn. Soc. Abras. Technol., Vol. 53, No. 1, (2009) pp.45-48. (in Japanese).

[6] K. Shimada et al: Ultrasonic-assisted micro-grinding with electroplated diamond wheels, 2nd Report: Effects of ultrasonic vibration on workpiece removal in grinding with wheel end, J. Jpn. Soc. Abras. Technol., Vol. 54, No. 1, (2010).
