Mathematical Modeling and Parametric Design of Taper End Mills

Abstract:

The mathematical modeling of the cutting tools is an important aspect for the design and manufacturing engineers from the viewpoint of shape realization. Taper mill is composed of side and end edges. In order to make each patch closely combined, the groove section is designed by considering the relation among tapered radius, groove depth and radius of inner land. Through translation and rotation of shape curve, the side flute and end flute model can be established. These models can be rendered in three dimensional software according to parametric design of taper end mills. And this methodology can be easily extended to design, manufacture other tools.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 574-578
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.574
• Online since: September 2013
• Authors: Li Lun He, Xi Bin Wang, Zhi Bing Liu, Ming Chen, Zong Wei Xu
• Keywords: Geometric Design, Helical Surface, Mathematical Modeling, Taper End Mill

References

[1] Stanaback, Harriet, Metlfax, 2001, 11: 42-46.

[2] Puneet Tandon, Md. Rajik Khan, Computer-Aided Design, 2009, 41: 106-114.

[3] Jung-Fa Hsieh, Psang Dain Lin, Inter. J. of Mach. Tools & Manu., 2003, 43: 1117-1127.

[5] L. Yao, Z. Ye, H. Cai, J. S. Dai. Proc. of the Inst. of Mech. Eng., Part C: J. of Mech. Eng. Sci., 2004, 218: 1233-1241.

[6] Wei-Ya Chen, Pai-Chi Chang, Shand-Dad Liaw, Wei-Fang Chen. J. of Mater. Proc. Tech., 2005, 161: 467-477.

[7] Chen WF. Proc Inst Mech Eng Part C: J. Mech. Eng. Sci., 2004, 218(3): 301-308.

[8] He YX, Zhou YF, Zhou J. Acta. Aeronaut. Astronaut. Sin., 2002, 23(2): 135-139.
