Composite Dowels in Bridges - Efficient Solution

Abstract:

The bridges are vital structures for the transport infrastructure; it is a fact that, in the last decades, composite bridges became a well-liked solution in many European countries as a cost-effective and aesthetic alternative to concrete bridges. Their competitiveness depends on several circumstances such as site conditions, local costs of material and staff and the contractors experience. Beside the classical solution, the new ones with efficient design and construction improve and consolidate the market position of the steel construction and steel producing industry. These bridge solutions combine many important aspects: reduced costs, fast and simple erection, durability and robustness, low maintenance costs and an appealing aesthetical aspect. Another feature is the robustness of composite bridges. The robustness of a structure has to be defined as being the capacity of the system to keep its structural integrity for any kind of action that may occur during its service life. The present tendency in composite bridges consists in simplifying the structure as much as possible. Continuous shear connection using a cut steel strip is a solution for composite beams. With the introduction of the composite dowel the possibility is given to develop new construction methods for bridges. The paper will include interesting aspects regarding the dimensioning of the structure and technological features and also aspects related to the efficiency, robustness and fatigue behavior of the joints with composite dowels in bridges. The behavior of the dowels has a theoretical background based on laboratory investigations. The Romanian railway and highway infrastructure is presently involved in a large operation of renewal and modernization. The solution was recently introduced in Romania for three highway bridges of medium spans.

• Periodical: Advanced Materials Research (Volume 814)
• Pages: 193-206
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.814.193
• Online since: September 2013
• Authors: Günter Seidl, Edward Petzek, Radu Băncilă
• Keywords: Bearing Capacity, Bridge Examples with Composite Dowels, Composite Dowels, Connections between Concrete and Steel, Fatigue Behavior, Innovative Cross Sections for Bridges

References

[1] V. Schmitt., G. Seidl, Verbundfertigteil-Bauweise im Brückenbau, Stahlbau, Berlin, Ernst & Sohn Verlag, 2001, 70.

DOI: 10.1002/stab.200101960

[2] V. Schmitt, G. Seidl, M. Hever, C. Zapfe Verbundbrücke Pöcking – Innovative VFT-Träger mit Betondübeln, [Hrsg.] Stahlbau, Berlin, Ernst & Sohn Verlag, 2004, Bd. 73 S. 387-393.

DOI: 10.1002/stab.200490108

[3] G. Seidl, A. Braun, VFT-WIB-Brücke bei Vigaun – Verbundbrücke mit externer Bewehrung, Stahlbau, Berlin, Ernst & Sohn Verlag, 2009, 78, S. 86-93.

DOI: 10.1002/stab.200910009

[4] G.Seidl, et alt. Prefabricated enduring composite beams based on innovative shear transmission, Final Report RFSR-CT-2006-00030, s.l.: European Commission, 2011.

[5] J. Berthellemy, O. Hechler, W. Lorenc, G. Seidl, Viefhuses E. Premiers résultats du projet de recherche européen Precobeam de connexion par découpe d'une tôle, Construction métallique, CTCIM 2009, vol 46, no 3, S. 3-26.

[6] G.Seidl, et alt., Brücken mit Verbunddübelleisten – Leitfaden, Dokument D767, RFCS preject PRECO+, FOSTA, 2012.

[7] J. Berthellemy, W. Lorenc, M. Mensinger, S. Rauscher, G. Seidl, Zum Tragverhalten von Verbunddübeln - Teil 1: Tragverhalten unter statischer Belastung, Stahlbau 80, Heft 3 2011, 172-184.

DOI: 10.1002/stab.201101408

[8] G. Seidl, Behaviour and load bearing capacity of composite dowels in steel-concrete composite girders, Dissertation, Wrocław University of Technology, Institut of Building Engineering, 2009.

[9] J. Berthellemy, W. Lorenc, M. Mensinger, J. Ndogmo, G. Seidl, Zum Tragverhalten von Verbunddübeln - Teil 2: Ermüdungsverhalten, Stahlbau 80, Heft 4 2011, 256-267.

DOI: 10.1002/stab.201101418

[10] EN 1993-1-9, Eurocode 3: Design of steel structures - Part 1-9: Fatigue, 2005.

[11] EcoBridge, Demonstration of economical bridge solutions based on innovative composite dowels and integrated abutments, RFSP-CT-2010-00024.

DOI: 10.1007/978-3-658-06417-4_1

[12] E. Petzek, R. Băncilă, V. Schmitt, Romanian experience in new efficient solutions for composite bridges, Eurosteel 2011 Budapest, 978-954-724-014-5, 2011.
