Formation of Anodic Oxide Nanotubes in H₂O₂ - Fluoride Ethylene Glycol Electrolyte as Template for Electrodeposition of α-Fe₂O₃

Abstract:

Anodic oxidation of titanium (Ti), zirconium (Zr) and niobium (Nb) foils in fluoride ethylene glycol (EG) added to it 1 H₂O₂ as oxidant was done to produce oxide film with nanostructures at 40 V. Whilst arrays of aligned nanotubes were successfully formed on the surface of Ti and Zr respectively, anodic Nb₂O₅ was found to consist of nanoporous structure with pore size of ~ 20 nm. Despite long nanotubes were formed on both Ti (2 μm) and Zr (3 μm), the surface of the nanotubes suffered from severe dissolution, thinning the wall and collapsing them. Well defined, ordered surface structure of the nanotubes is required as they will be used as template for subsequent deposition of nanoparticles. This was achieved when Ti anodised in 5 ml H₂O₂ fluoride EG. With excess H₂O₂ etching at the surface occur more uniformly forming homogenous surface structure. α-Fe₂O₃ were then electrodeposited on this surface at-3 V from chloride solution and the mode of formation is believed to be due to electrogeneration of base at the surface of the TiO₂.

• Periodical: Advanced Materials Research (Volume 832)
• Pages: 333-337
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.832.333
• Online since: November 2013
• Authors: Zainovia Lockman, Dede Miftahul Anwar, Monna Rozana, Syahriza Ismail, Ehsan Ahmadi, Abdul Razak Khairunisak, Kuan Yew Cheong
• Keywords: Anodisation, Electrodeposition, Fe₂O₃, TiO₂, Zro₂

References

[1] Sulka, G.D., Highly Ordered Anodic Porous Alumina Formation by Self-Organized Anodizing, in Nanostructured Materials in Electrochemistry. 2008, Wiley-VCH Verlag GmbH & Co. KGaA. pp.1-116.

DOI: 10.1002/9783527621507.ch1

[2] Schmuki, P., From Bacon to barriers: a review on the passivity of metals and alloys. Journal of Solid State Electrochemistry, 2002. 6(3): pp.145-164.

DOI: 10.1007/s100080100219

[3] Liang, Y.Q., et al., Formation and characterization of iron oxide nanoparticles loaded on self-organized TiO2 nanotubes. Electrochimica Acta, 2010. 55(18): pp.5245-5252.

DOI: 10.1016/j.electacta.2010.04.053

[4] Raja, K.S., T. Gandhi, and M. Misra, Effect of water content of ethylene glycol as electrolyte for synthesis of ordered titania nanotubes. Electrochemistry Communications, 2007. 9(5): pp.1069-1076.

DOI: 10.1016/j.elecom.2006.12.024

[5] Lee, K., et al., Formation of Highly Ordered Nanochannel Nb Oxide by Self-Organizing Anodization. Chemistry – A European Journal, 2012. 18(31): pp.9521-9524.

DOI: 10.1002/chem.201201426

[6] Lockman, Z., et al., Effect of Anodisation Parameters on the Formation of Porous Anodic Oxide on Ti, Zr and W. IOP Conference Series: Materials Science and Engineering, 2011. 18(5): p.052004.

DOI: 10.1088/1757-899x/18/5/052004

[7] Korotcenkov, G., et al., Successive ionic layer deposition: possibilities for gas sensor applications. Journal of Physics: Conference Series, 2005. 15(1): p.45.

DOI: 10.1088/1742-6596/15/1/008

[8] Zhitomirsky, I., Cathodic electrodeposition of ceramic and organoceramic materials. Fundamental aspects. Advances in Colloid and Interface Science, 2002. 97(1–3): pp.279-317. 70 nm

DOI: 10.1016/s0001-8686(01)00068-9
