In Situ Detection of Partial Discharge Using Leakage Current, Fiber Optic Sensor and Piezoelectric Sensor Techniques

Abstract:

The partial discharge (PD) phenomenon is very harmful for electrical appliances and its early detection could be a cost effective approach for the industry. Although many techniques are used for PD detection yet no technique has presented widely acceptable solution. Still the subject needs parallel study of the detection techniques. In this study, partial discharge signal has been captured by the three techniques using fiber optic sensor (FOS), Piezoelectric Sensor (PZT), leakage current (LC) techniques. In these experiments, FOS shows good sensitivity in the range of applied high voltage > 5 kV. The sensitivity and noise level of PD signal was different in these two experiments.

• Periodical: Advanced Materials Research (Volume 845)
• Pages: 277-282
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.845.277
• Online since: December 2013
• Authors: Mohd Muhridza Yaacob, Malik Abdulrazzaq Alsaedi
• Keywords: Acoustic Emission (AE), Leakage Current Sensing Method, Multimode Optical Fiber, Oil-Insulation Transformer, Optical Fiber Sensor (OFS), Partial Discharge (PD), Piezoelectric Sensor

References

[1] T. J. Schwarz, Review of Partial Discharge Monitoring techniques used in High Voltage Equipment, Conference, Annual Report Insulation, Electrical Phenomena, Dielectric Engineering, High Voltage, p.400–403, (2008).

DOI: 10.1109/ceidp.2008.4772825

[2] IEC 60270, High-voltage test techniques – Partial discharge measurements, (2000).

[3] C. X. Chen, G., Xu Yang , Yu Ming, Comparison between optical and electrical methods for partial discharge measurement, Proceedings of the 6th International Conference on Properties and Applications of Dielectric Materials (Cat. No. 00CH36347), p.300–303, (2000).

DOI: 10.1109/icpadm.2000.875690

[4] J. Papy, S. V. Huffel, L. Rippert, and M. Wevers, On-line detection method for transient waves applied to continuous health monitoring of carbon fiber reinforced polymer composites with embedded optical fibers, International Conference on Smart Structures and Materials, vol. 5049, no. May 2012, p.718–731, (2003).

DOI: 10.1117/12.484061

[5] L. Rippert, J. Papy, M. Wevers, and S. V. Huffel, Fibre optic sensor for continuous health monitoring in CFRP composite materials, International Symposium on Smart Structures and Materials, p.312–323, San Dieago, (2002).

DOI: 10.1117/12.475228

[6] M. R. Layton and J. a Bucaro, Optical fiber acoustic sensor utilizing mode-mode interference, Applied optics, Vol. 18, no. 5, : 666–70, Mar. (1979).

DOI: 10.1364/ao.18.000666

[7] G. Yilmaz and S. E. Karlik, A distributed optical fiber sensor for temperature detection in power cables, Sensors and Actuators A: Physical, Vol. 125, no. 2,: 148–155, Jan. (2006).

DOI: 10.1016/j.sna.2005.06.024
